Display (lower or upper line)
Description
LOAD|■■■■| | ####
Bar graph representing hydraulic operating pressure.
Full scale is pre-programmed overload pressure
(2500–5000 psi). If sensor disabled, LOAD does not
display
7
##.# VOLTS
Engine electrical system operating voltage.
SCROLL
SUB-MENU (Lower Line Only)
#### KNIFE SPEED
##.# HEADER HEIGHT
LOAD|■■■■|■■■■| ####
##.## REEL MPH
##.# DRAPER SPEED
Displays sub-menu after 2–3 seconds. Press SELECT to
cancel. Scroll through sub-menu display with CDM switch.
KNIFE SPD OVERLOAD
Cab-Forward, Engine Running, Header Engaged, Draper Header, Index Switch ON
Scroll through display with cab display module (CDM) switch or ground speed lever (GSL) switch.
Display (lower or upper line)
Description
#####.# ENGINE HRS
Total engine operating time.
#####.# HEADER HRS
Total header operating time.
##.# ACRES/HOUR
##.# HECTARES/HOUR (if metric)
Actual cutting rate in acres (hectares)/hour.
###.# SUB ACRES
###.# SUB HECTARES (if metric)
Area cut since last reset. To reset, display SUB ACRES
on lower line and hold down program switch until display
resets (5–7 Seconds).
###### TOTAL ACRES
###### TOTAL HECT (if metric)
Total area cut by machine.
##.## ##.# REEL IND
REEL.SENSOR
Reel peripheral speed along with ground speed in mph or
kph.
Sensor Disabled. IND and SENSOR alternate at 1 second
intervals.
##.# ##.# DRAP INDX
Draper speed along with ground speed in mph or kph.
#### KNIFE SPEED
#### KNIFE SENSOR
Knife speed in strokes per minute. Sensor Disabled.
SPEED and SENSOR alternate at 1 second intervals.
##.# HEADER HEIGHT
##.# HEADER SENSOR
Distance setting (00.0–10.0) between cutterbar and ground.
Sensor Disabled. HEIGHT and SENSOR alternate at 1
second intervals.
##.# HEADER ANGLE
##.# HEADER SENSOR
Angle setting (00.0–10.0) header relative to ground.
Sensor Disabled. ANGLE and SENSOR alternate at 1
second intervals.
7.
The LOAD sensor to monitor knife/conditioner circuit pressure is optional. To monitor reel/auger circuit pressure, relocate
sensor as per Form MD #169031, which is available through your Dealer.
