OPERATION
Electrical
The electrical system voltage is displayed on the cab display module (CDM) when selected with the SELECT
button on the ground speed lever (GSL) handle or the SELECT switch on the CDM. The display indicates the
condition of the battery and alternator.
Ignition Engine Reading Indicated Condition
13.8–15.0 Normal
> 16.0 13 Regulator out of adjustment Running
< 12.5 13 Alternator not working or regulator out of adjustment
ON
Shut down 12.0 Battery normal
Engine Warning Lights
There are four engine warning lights that illuminate if abnormal conditions occur while the engine is running. The
engine warning lights should NOT be illuminated under normal operating conditions. For more information, refer to
Engine Warning Lights, page 82 .
4.3.6 Windrower Operation
WARNING
• Before starting engine, securely fasten your seat belt and ensure trainer’s seat belt is fastened
if occupied.
• The seat belt can help ensure your safety if it is used and maintained.
• Never wear a seat belt loosely or with slack in the belt system. Never wear the belt in a twisted condition
or pinched between the seat structural members.
WARNING
• Avoid driving the machine with header removed. Removing header decreases the weight on drive
wheels, reducing steering control.
• If necessary to drive machine with header removed, use transmission field speed range, do NOT exceed
1500 rpm engine speed and avoid loose gravel and slopes.
• Never use windrower as a towing vehicle when header is removed, except as instructed in Towing
Header with Windrower, page 124 . There is insufficient weight on the drive wheels to provide steering
control.
• Because of windrower shape characteristics, a roll-over protected (ROPS) cab is not required. If
operating with header removed, be aware that cab structure will NOT withstand a roll-over.
13. Display flashes voltage reading with single loud tone. Repeats every 30 minutes until condition is fixed.
