OPTIONS AND ATTACHMENTS
7.1.23 Weight Box
To move the windrower without an attached header, attach the weight box to the header lift system. The weight
box allows transporting a header behind the windrower by providing additional weight on the drive wheels.
MD #B5238 – Weight box without harness 34
MD #B5240 – Weight box without harness and concrete. 34
Instruction MD #169280 is included with the bundle.
MD #B5280 – Wiring harness for weight box. Includes hitch pin and wiring for use with slow speed transport. Use
with MD #B5238 and MD #B5240. Required when towing header with SP windrower.
Instruction MD #169278 is included with the bundle.
7.1.24 Windshield Shades
Retractable sun shades for front and rear windows. Attachment hardware is included.
MD #B4866
Instruction MD #169218 is included with the bundle.
34. Wiring harness MD #B5280 is also required to tow a header. Refer to 7.1.21 Towing Harness, page 408
169883
409
Revision A
