HEADER LIFT/TILT
Type
Hydraulic Double Acting Cylinders. Tilt - Optional Hydraulic Positioning,
Optional Hydraulic Center-Link
Function
Lift / Tilt / Float
HEADER FLOAT
Primary
Adjustment
Manual, External, Drawbolt With Springs (1 per side). One Inner Booster
Spring On Left Side.
Fine Adjustment
Hydraulic, In-Cab Switch
Automatic
Hydraulic, 3 Programmable Settings For All Headers
(Deck Shift Compensation On Draper Headers)
CAB
Type
Spring/Shock Suspension
Width
63 in. (1600 mm)
Depth
68.3 in. (1735 mm) (at top of window)
Height
64.6 in. (1640 mm)
Dimensions
Volume
125 cu. ft. (3540 L)
Driver
Adjustable Air-Ride Suspension, Seat Belt
Seat
Training
Folding, Cab Mounted, Seat Belt
Front
31.5 in. (800 mm) Blade
Windshield
Wiper
Rear
22 in. (560 mm) Blade
Heater
24,000 Btu/h (7038 W)
Air Conditioning
28,280 Btu/h (8288 W)
Electrical Outlets
One Live, Two On Ignition, One Live/Keyed
Mirrors
One Inside (Transport), Two Outside (Field)
Radio
Two Speakers and Antenna Factory Installed. Radio Dealer Installed
SYSTEM MONITORING
Speeds
Ground (mph or km/h), Engine (rpm), Knife (spm), Disc (rpm),
Reel (rpm or mph/km/h), Conveyor (Ref. No.)
Header
Height, Angle, Float, Header Drive Load Gauge
TIRE OPTIONS
(Refer to
for options.)
FRAME AND STRUCTURE
Dimensions
Refer to
2.3 Windrower Dimensions, page 32
Frame to Ground (Crop Clearance) 45.7 in. (1160 mm)
Base
9610 lbs (4360 kg)
1
Maximum GVW
21,500 lbs (9750 kg)
Weight
Maximum CGVW
23,100 lbs (10,480 kg)
1.
Weights do not include options.
