Lenze DDS v2.3 - Manual (Page 82)

Drive PLC Developer Studio
Working with projects and objects
6-4
l
DDS EN 2.3
3. Compile the project.
Note!
After compiling the project must be saved once. While the project is saved, DDS creates files which
are part of the ZIP archive.
4. Open the following dialog with the menu command File
WSave/mail archive. Only tick (project
file, referenced libraries, compile information and bitmap files). This menu item can only be
ticked if a bitmap is contained in the project. If no bitmaps are contained, you can ignore this
item.
5. If you have ticked the items save the archive.
Include the following information into the archive
Apart from the procedure described, the ZIP archive can also be used in general.
A category must be selected with (
ü).
Category Relevant files
Project file .pro (the DDS project file)
Referenced libraries *.lib, *.obj, *.hex (libraries and, if necessary, the associated obj and hex files)
Compile information *.ci (information specific to the last compile)
*.ri (information specific to the last download)
.* (temporary compilation and download files) also for simulation
INI file DDS.ini
Log file *.log (project log file)
Bitmap files *.bmp (bitmaps used in project organization units and visualizations)
Registry entries Registry.reg (entries for Automation Alliance, gateway and PLC)
Icon files *.sdb, *.sym (icon information generated from the project)
Configuration files PLC configuration files
(configuration files, device master files, icons, etc.)
e.g. *.cfg *.con *.eds *.dib *.ico...
Target files *.trg (binary-format target files for all installed targets)
*.txt (binary-format target files for all installed targets, if available)
Local gateway Gateway files: Gateway.exe, GatewayDDE.exe, GClient.dll, GDrvBase.dll, GDrvStd.dll, Ghandle.dll, GSymbol.dll,
GUtil.dll and other DLLs in the gateway directory
