Drive PLC Developer Studio
Working area
5-17
l
DDS EN 2.3
Commands
This dialog box defines or edits commands for the macro. A new command line is inserted by
pressing +.The right mouse key displays the shortcut menu with standard editor
functions. Components of a command that belong together can be concatenated with the help of
quotes.
Macro commands - commands
The appendix includes a list of all macros.
Command line commands ( ^ 15-1)
Command file commands ( ^ 15-2)
Menu
This dialog box defines the menu entry to insert the macro under
Edit
WMacros.
Place an & in front of a letter to turn it into a shortcut. The name Ma&cro 1 generates menu entry
Macro 1.
OK
Exits the dialog box and saves the input in the project.
A macro check will be performed only at the time the menu command is executed.
OptionsWGDC Device Description
Use this dialog box to select whether a project-specific device description file (PDB) is to be created
for Global Drive Control (GDC) and, if so, for which languages.
Tip!
A PDB will be created only if a directory has been specified under Path and the check box
Build GDC Device Description has been activated. The PDB is built/updated on project compile
if PDB-relevant data have changed.
The file name of the PDB consists of the project name followed by an index (” _S” , ” _1” , ” _2” ) for the
associated language and the extension ” .pdb” .
Example:
•
Name of the project: ” Example”
•
Language selection: Standard language and Language Two
• Þ PDB file names: ”Example_S.pdb” and ”Example_2.pdb”
