Lenze DDS v2.3 - Manual (Page 328)

Drive PLC Developer Studio
Appendix
15-18
l
DDS EN 2.3
No. Possible remedy Cause
4358 Undeclared action: Ensure that the IEC step action is inserted in the Object Organizer below the SFC organization
unit, and that the action name is entered in the box to the right of the qualifier.
4359 Invalid qualifier: Enter a qualifier for the IEC action in the box to the left of the action name.
4360 Time constant expected behind qualifier: Enter a time constant behind the qualifier for the IEC action in the box to the left of the
action name.
4361 Identifier identifies no action Enter the name of an action or a Boolean variable defined in the project for the IEC action in
the box to the right of the qualifier.
4362 Non-Boolean expression in action: Enter a Boolean variable or a valid action name.
4363 IEC step name already in use for variable: Rename the step or the variable.
4364 A transition must be a Boolean expression The result of the transition expression must be BOOL-type.
4365 Step has an incorrect time limit value Open the dialog Step attributes for step and enter valid time variables or constants.
4366 The label for the parallel step is no permissible identifier:
Enter a valid identifier next to the triangle identifying the jump label.
4367 The label already exists You have already assigned this name to a jump label or a step. Rename accordingly.
4368 Action used on several superimposed SFC levels ! You are using the action both in the organization unit as well as in one or several
actions of this organization unit.
4369 Exactly one network required for transitions You have used several FBD or LD networks for the transition.
Reduce to exactly one network.
4370 Superfluous lines behind correct IL transition Delete the superfluous lines at the transition end.
4371 Superfluous characters after valid expression: Delete the superfluous characters at the transition end.
4400 Organization unit imported or converted
incomplete / with errors. The organization cannot be converted completely to IEC 61131-3.
4401 S5 time constant seconds too high (max.
9990s). No valid BCD-coded time in accumulator.
4402 Direct access permitted to I/Os only. Ensure that you are only accessing a variable defined as input or output.
4403 STEP5/7 command invalid or inconvertible to IEC 61131-3 Not every STEP 5/7 command can be converted to IEC 61131-3 (such as CPU commands like
MAS, for example).
4404 STEP5/7 operand invalid or inconvertible to IEC 61131-3 Not every STEP5/7 operand can be converted to IEC 61131-3, or one operand missing.
4405 Reset of a STEP5/7 timer cannot be converted to
IEC 61131-3. The associated IEC timers have no Reset input.
4406 STEP5/7 counter constant too high (max. 999). No valid BCD-coded counter constant in accumulator.
4407 STEP5/7 instruction cannot be converted to IEC 61131-3 Not every STEP5/7 instruction can be converted to IEC 61131-3 (such as DUF, for example).
4408 Bit access to timer / counter words cannot be converted to
IEC 61131-3. Specific timer / counter commands cannot be converted to IEC 61131-3.
4409 Accu1 or Accu2 contents undefined, cannot be
converted to IEC 61131-3. A command linking the two accumulators cannot be converted as the accumulator contents
are not known.
4410 Called organization unit not in project Import the called organization unit.
4411 Error in global variable list. Check the SEQ file.
4412 Internal error no.11 Contact the control manufacturer.
4413 Incorrect format of a line within data organization unit Code to be imported contains an incorrect date.
4414 FB/FX name missing The symbolic name of an (extended) function block is missing from the original S5D file.
4415 Command not allowed after organization unit end A protected organization unit cannot be imported.
4416 Invalid command The S5/S7 command cannot be disassembled.
4417 Incomplete comment Complete the comment with *).
4418 FB/FX name too long (max. 8 characters) The symbolic name of an (extended) function block is too long.
4419 Expected line format (* Name: *) Correct the line accordingly.
4420 FB/FX parameter name missing Check the function blocks.
4421 FB/FX parameter type name invalid Check the function blocks.
4422 FB/FX parameter type not specified Check the function blocks.
4423 Invalid actual operand Check the function block interface.
4424 Warning: Called organization unit does not exist, or header
incorrect or has no parameters The called function block has either not been imported yet, is faulty or has no parameters
(ignore the message in the latter case).
4425 No jump label defined The target of a jump has not been specified.
4426 Organization unit has no valid STEP5 name such as PB10,
for example. Change the organization unit name.
4427 No timer type specified Insert a timer declaration into the global variable list.
4428 Maximum STEP5/7 parenthesis nesting depth exceeded No more than seven left parentheses may be used.
4429 Error in formal parameter name The parameter name must not be longer than four characters.
4430 Formal parameter type cannot be converted to IEC Timers, counters and organization units cannot be converted as formal parameters to
IEC 61131-3.
4431 Too many VAR_OUTPUT parameters for a call in STEP5/7 IL An organization unit must not contain in excess of sixteen formal parameters as outputs
