9.3.2 Formatted text display
The following tables provide a general formatted text display.
Char format
Element Meaning
% Formatted text display starts with %. If the character is to be included in the display for specific reasons, the first characters
must be %%.
- Display is left-aligned.
b Display field minimum width
c For Char variables
String format
Element Meaning
% Formatted text display starts with %. If the character is to be included in the display for specific reasons, the first characters
must be %%.
- Display is left-aligned.
b Display field minimum width
.n Width of the field section written by the string
s For Char arrays
Integer format
Element Meaning
% Formatted text display starts with %. If the character is to be included in the display for specific reasons, the first characters
must be %%.
- Display is left-aligned.
+ Positive polarity
b Display field minimum width
.n Minimum number of display digits
Only one of the characters listed below appears at the end of the formatted text
d
For Int variables
ld For long Int variables
Format for polarity-free integers
Element Meaning
% Formatted text display starts with %. If the character is to be included in the display for specific reasons, the first characters
must be %%.
- Display is left-aligned.
# Leading zero for hexadecimal and octal representation
b Display field minimum width
.n Minimum number of display digits
Only one of the characters listed below appears at the end of the formatted text
d
Number in decimal 0-9
x Number in hexadecimal 0-9 and a-f
X Number in hexadecimal 0-9 and A-F
o Octal 0-7 for polarity-free variables
