8.8.6.2 Insert program call / Add program call
Icon: -
- Menu: InsertWInsert program call
InsertWAdd program call
Keyboard: -
-
Use this command to open the dialog box and enter a program call for a task in the task
configuration.
Select Insert program call to insert the new program call in front of the cursor and
Add program call to add the program call to the end of the existing list.
Use the input field Program call to enter a valid program name, or press ... to open the Help Manager
for a selection of valid program names.
If the selected program requires input variables, enter these as shown in the example:
Example of input variable:
prg(invar:=17)
8.8.6.3 Properties
Icon: - Menu: Extras WProperties Keyboard:
Depending on the selected element, use this command to open the dialog box Task properties or
the dialog box Program call in the task configuration.
•
If the cursor is positioned over a task entry to which no list of program calls has been added
yet, open the dialog box Task properties by double-clicking the entry or pressing .
•
If the cursor is positioned over an entry for a program call, double-click the entry to open the
dialog box
Program entry
•
Click a task or program name or press the to draw an editing frame around the
name. The name can then be changed directly in the task editor.
