Drive PLC Developer Studio
Visualization
9-18
l
DDS EN 2.3
ConfigureWBitmap available for: Bitmap
Use Extras
➞ ➞ ➞ ➞Configure, category Bitmap to effect settings for the selected bitmap.
Bitmap
Use the input field Bitmap to enter the bitmap file and its path.
•
Click ... to open the standard dialog for browsing through the file structure to select the
required file.
•
Use check box Transparent background to define a colour contained in the bitmap as
transparent. Use the button Transparent colour to define the colour.
Frame
•
If check box Anisotropic is activated, the bitmap fills its frame and its size can be changed.
•
If check box Isotropic is activated, the proportions of the bitmap always remain the same
even if the size changes, i.e. the ratio between length and width remains the same.
•
If check box Fixed is activated, the bitmap will be displayed in its original size, independent
of its frame.
•
If check box Cut off is activated, the setting Fixed only displays the framed part of the
bitmap.
•
If check box Draw is activated, the frame will be displayed in the colour selected under
Colour and Signal colour. The signal colour will only be displayed if the variable entered in
the category Variables, field
Change colour is TRUE.
ConfigureWVisualization available for: visualization
Use Extras
➞ ➞ ➞ ➞Configure, category Visualization to effect the settings for a visualization inserted into
the current visualization as an element. After insertion, this one is referred to as the Reference of
the original one.
Visualization
Use the input field Visualization to enter the object name of the visualization.
•
All visualizations except the current visualization and a reference to the current one can be
specified.
•
Click ... to open the dialog box Select visualization to see a list of all visualizations available
for this project.
Frame
•
If check box Draw is activated, the frame will be displayed in the colour selected under
Colour and Signal colour . The signal colour will only be displayed if the variable entered in
the category
Variables , field Change colour is TRUE.
•
If check box Isotropic is activated, the proportions of the visualization always remain the
same even if the size changes, i.e. the ratio between length and width remains the same.
•
If check box Cut off is activated, only the original section of the visualization will be displayed
in online mode. If an object reaches beyond the original display, for example, this object will
be cut off and may not be visible any more.
