Drive PLC Developer Studio

Working area

5-1

l

DDS EN 2.3

5

Desktop

5.1

User interface



‚

ƒ

„

…

†

‡

The DDS user interface consists of the following elements:

 Menu bar

‚ Tool bar (optional)

ƒ Object Organizer

„ Vertical screen divider between the Object Organizer and the DDS desktop.

… Desktop with the editor windows.

† Message window (optional)

‡ Status bar (optional)

5.1.1

Menu bar

The menu bar is located at the top end of the main window and contains all DDS menu commands.
