Drive PLC Developer Studio

Editors

7-27

l

DDS EN 2.3

7.4.4

Inputs/ Outputs on the fly

This function serves to create inputs and outputs whether via keyboard entry or by means of a
selection field.

Tip!

This function saves you from drawing and connecting inputs, outputs, and function blocks in the
CFC editor.

Select, for example, an input or output in the CFC editor.

Enter the variable name directly via the keyboard. If the variables are already available the name
must be written correctly. If the variable is not available, it must be set in the variable declaration.

If the name or the instance name of a function block or structure is entered with a point, a list of all
variables is displayed.
