Lenze DDS v2.3 - Manual (Page 326)

Drive PLC Developer Studio
Appendix
15-16
l
DDS EN 2.3
No. Possible remedy Cause
4061 VAR_IN_OUT parameter of must be
assigned. Write-accessible variables must be assigned to VAR_IN_OUT parameters as these can be
modified within the organization unit.
4062 No external access to VAR_IN_OUT parameter of
. VAR_IN_OUT parameters must only be written or read within the organization unit (reference
transfer).
4063 VAR_IN_OUT parameter of cannot be
assigned bit addresses. A bit address is no valid physical address.
Transfer a variable or a direct non-bit address.
4064 VAR_IN_OUT must not be overwritten in local action call ! Delete the assignment of the VAR_IN_OUT variables for the local action call.
4070 Too deeply nested expression in organization unit. Reduce the nesting depth by distributing the expression across several expressions with the
help of assignments to intermediate variables.
4071 Network too large Divide the network into several networks.
4100 ^ requires a pointer type You are attempting to dereference a variable that has not been declared as POINTER TO.
4110 [] only allowed for array variables You are using [] for a variable that has not been declared as ARRAY OF.
4111 The expression in the index of an array must have an
INT-type result. Use an expression of the respective type, or a type conversion.
4112 Too many array indices Check the number of indices (1, 2, or 3) for which the array has been declared, and remove
the superfluous indices.
4113 Insufficient array indices Check the number of indices (1, 2, or 3) for which the array has been declared, and add the
missing indices.
4114 Constant index outside array boundaries Ensure that the applied indices range within the array boundaries.
4120 A ” . ” must be preceded by a structure variable. The identifier to the left of the period must be a STRUCT or FUNCTION_BLOCK-type variable
or the name of a FUNCTION or a PROGRAM.
4121 is no component of .The component is not included in the definition of object .4122 is not an input parameter of the called function
block.Check the input variables of the called function block, and change into one of these
variables.4200LD expectedAdd at least one LD instruction in the editor window of the IL organization unit or behind the
jump label.4201IL operator expectedEvery IL instruction must start with an operator or a jump label.4202Unexpected end of the subexpressionInsert the right parenthesis.4203 in parentheses not allowedThe specified operator is not permitted within an IL subexpression.
(impermissible are: JMP, RET, CAL, LDN, LD, TIME)4204Right parenthesis without left parenthesis.Insert left parenthesis, or delete right parenthesis.4205No comma permitted after )Remove the comma behind the right parenthesis.4206No jump labels in subexpressions.Move the jump label outside the subexpression.4207N modifier requires a BOOL, BYTE, WORD or DWORD-type
operand.The N modifier requires a data type for which a Boolean negation can be performed.4208The expression in front of a conditional command must
return a BOOL-type resultEnsure that the expression returns a Boolean result, or use a type conversion.4209Function names are not allowed here.Replace the function call with a variable or constant.4210CAL, CALC and CALN require a function block instance as
an operandDeclare an instance of the function block to be called.4211Comments in IL at the end of the line only.Move the comment to the end of the line or into a separate line.4212Accumulator invalid before conditional instructionThe accumulator content is not defined.
This is the case after instructions that do not return any result (CAL, for example).4213S and R require a BOOL-type operandUse a Boolean variable at this position.4250No correct start for an ST instructionThe line does not start with a correct ST instruction.4251Function has too many parameters.More parameters were specified than were declared in the function definition.4252Function has insufficient parameters.Fewer parameters were specified than were declared in the function definition.4253IF and ELSIF require a Boolean expression as conditionEnsure that the condition following an IF and ELSIF is a Boolean expression.4254WHILE requires a Boolean expression as conditionEnsure that the condition following a WHILE is a Boolean expression.4255UNTIL requires a Boolean expression as conditionEnsure that the condition following an UNTIL is a Boolean expression.4256NOT requires a Boolean operand.Ensure that the condition following a NOT is a Boolean expression.4257The counter of the FOR instruction must be INT-typeEnsure that the counter variable is an integer or bitstring data type (DINT, DWORD, for
example).4258The counter in the FOR instruction is no write-accessible
variableReplace the counter variable with a write-accessible variable.4259The start value of the FOR instruction must be INT-type.The start value of the FOR instruction must be compatible with the counter variable type.4260The end value of the FOR instruction must be INT-type.The end value of the FOR instruction must be compatible with the counter variable type.4261The incrementation value of the FOR instruction must be
INT-type.The incrementation value of the FOR instruction must be compatible with the counter
variable type.4262EXIT is permitted only within a loop.Use EXIT only within FOR, WHILE or UNTIL instructions.4263Number, ELSE or END_CASE expectedOnly a number or an ELSE instruction, or the end instruction END_CASE, can be specified
within a CASE.Show/Hide Bookmarks Pages: 1 … 324 325 326 327 328 … 340 wrong Brand wrong Model non readable See also other documents in the category Lenze Hardware: ESMD smd tmd remote keypad (4 pages) EPM Programmer EEPM1RA (114 pages) ESMDC (36 pages) SMD Frequency Inverter 0.37kW-22kW (116 pages) SMD Frequency Inverter: Basic I/O with CANopen 0.25kW-4.0kW (36 pages) SMD 0-25kW-4-0kW (112 pages) smd Series Drives (32 pages) ESV SMV remote keypad H0 (2 pages) ESV SMV remote keypad H1 (2 pages) SV SMV additional I-O module (14 pages) EEPM1RA EPM (26 pages) SMVector RS-485 LECOM (29 pages) E84AYM10S (4 pages) E84AYCET EtherCAT MCI module (109 pages) EZAMBKBM (6 pages) E84AYCEC (89 pages) ERBPxxxRxxxx Brake resistor 200W-300W (134 pages) E84AYCPM (115 pages) E84AYCEO (165 pages) E84AYCER (94 pages) E84AVSCx 8400 StateLine C (76 pages) EZVxxxx-000 Power supply unit AC 230V 5A-20A (62 pages) E84AYCIB (75 pages) E82ZWBRB (48 pages) EZVxx00−001 Power supply unit AC 400V 5A-20A (64 pages) E82ZWBRE (64 pages) EZAEBK1001 (94 pages) E94AYAE SM301 (134 pages) E94AYAE SM301 (74 pages) E94AYAE SM301 (140 pages) E94AZPS (114 pages) E94AYCIB (78 pages) E94AYCIB (124 pages) E94AZEX100 (84 pages) EZS3-xxxA200 Sinusoidal filter 115-150A (44 pages) E94AZHA0051 (104 pages) E94AZCDM030 (72 pages) EZS3-xxxA200 Sinusoidal filter 180-480A (74 pages) E94AYCCA (188 pages) E94AYCCA (114 pages) E94AZHB0101 (104 pages) E94AYCPM (125 pages) E94AYCPM (114 pages) E94AYCET (140 pages) E94AYCET (103 pages) Sitemap The component is not included in the definition of object .4122 is not an input parameter of the called function
block.Check the input variables of the called function block, and change into one of these
variables.4200LD expectedAdd at least one LD instruction in the editor window of the IL organization unit or behind the
jump label.4201IL operator expectedEvery IL instruction must start with an operator or a jump label.4202Unexpected end of the subexpressionInsert the right parenthesis.4203 in parentheses not allowedThe specified operator is not permitted within an IL subexpression.
(impermissible are: JMP, RET, CAL, LDN, LD, TIME)4204Right parenthesis without left parenthesis.Insert left parenthesis, or delete right parenthesis.4205No comma permitted after )Remove the comma behind the right parenthesis.4206No jump labels in subexpressions.Move the jump label outside the subexpression.4207N modifier requires a BOOL, BYTE, WORD or DWORD-type
operand.The N modifier requires a data type for which a Boolean negation can be performed.4208The expression in front of a conditional command must
return a BOOL-type resultEnsure that the expression returns a Boolean result, or use a type conversion.4209Function names are not allowed here.Replace the function call with a variable or constant.4210CAL, CALC and CALN require a function block instance as
an operandDeclare an instance of the function block to be called.4211Comments in IL at the end of the line only.Move the comment to the end of the line or into a separate line.4212Accumulator invalid before conditional instructionThe accumulator content is not defined.
This is the case after instructions that do not return any result (CAL, for example).4213S and R require a BOOL-type operandUse a Boolean variable at this position.4250No correct start for an ST instructionThe line does not start with a correct ST instruction.4251Function has too many parameters.More parameters were specified than were declared in the function definition.4252Function has insufficient parameters.Fewer parameters were specified than were declared in the function definition.4253IF and ELSIF require a Boolean expression as conditionEnsure that the condition following an IF and ELSIF is a Boolean expression.4254WHILE requires a Boolean expression as conditionEnsure that the condition following a WHILE is a Boolean expression.4255UNTIL requires a Boolean expression as conditionEnsure that the condition following an UNTIL is a Boolean expression.4256NOT requires a Boolean operand.Ensure that the condition following a NOT is a Boolean expression.4257The counter of the FOR instruction must be INT-typeEnsure that the counter variable is an integer or bitstring data type (DINT, DWORD, for
example).4258The counter in the FOR instruction is no write-accessible
variableReplace the counter variable with a write-accessible variable.4259The start value of the FOR instruction must be INT-type.The start value of the FOR instruction must be compatible with the counter variable type.4260The end value of the FOR instruction must be INT-type.The end value of the FOR instruction must be compatible with the counter variable type.4261The incrementation value of the FOR instruction must be
INT-type.The incrementation value of the FOR instruction must be compatible with the counter
variable type.4262EXIT is permitted only within a loop.Use EXIT only within FOR, WHILE or UNTIL instructions.4263Number, ELSE or END_CASE expectedOnly a number or an ELSE instruction, or the end instruction END_CASE, can be specified
within a CASE.Show/Hide Bookmarks Pages: 1 … 324 325 326 327 328 … 340 wrong Brand wrong Model non readable See also other documents in the category Lenze Hardware: ESMD smd tmd remote keypad (4 pages) EPM Programmer EEPM1RA (114 pages) ESMDC (36 pages) SMD Frequency Inverter 0.37kW-22kW (116 pages) SMD Frequency Inverter: Basic I/O with CANopen 0.25kW-4.0kW (36 pages) SMD 0-25kW-4-0kW (112 pages) smd Series Drives (32 pages) ESV SMV remote keypad H0 (2 pages) ESV SMV remote keypad H1 (2 pages) SV SMV additional I-O module (14 pages) EEPM1RA EPM (26 pages) SMVector RS-485 LECOM (29 pages) E84AYM10S (4 pages) E84AYCET EtherCAT MCI module (109 pages) EZAMBKBM (6 pages) E84AYCEC (89 pages) ERBPxxxRxxxx Brake resistor 200W-300W (134 pages) E84AYCPM (115 pages) E84AYCEO (165 pages) E84AYCER (94 pages) E84AVSCx 8400 StateLine C (76 pages) EZVxxxx-000 Power supply unit AC 230V 5A-20A (62 pages) E84AYCIB (75 pages) E82ZWBRB (48 pages) EZVxx00−001 Power supply unit AC 400V 5A-20A (64 pages) E82ZWBRE (64 pages) EZAEBK1001 (94 pages) E94AYAE SM301 (134 pages) E94AYAE SM301 (74 pages) E94AYAE SM301 (140 pages) E94AZPS (114 pages) E94AYCIB (78 pages) E94AYCIB (124 pages) E94AZEX100 (84 pages) EZS3-xxxA200 Sinusoidal filter 115-150A (44 pages) E94AZHA0051 (104 pages) E94AZCDM030 (72 pages) EZS3-xxxA200 Sinusoidal filter 180-480A (74 pages) E94AYCCA (188 pages) E94AYCCA (114 pages) E94AZHB0101 (104 pages) E94AYCPM (125 pages) E94AYCPM (114 pages) E94AYCET (140 pages) E94AYCET (103 pages) Sitemap
4122 is not an input parameter of the called function
block. Check the input variables of the called function block, and change into one of these
variables.
4200 LD expected Add at least one LD instruction in the editor window of the IL organization unit or behind the
jump label.
4201 IL operator expected Every IL instruction must start with an operator or a jump label.
4202 Unexpected end of the subexpression Insert the right parenthesis.
4203 in parentheses not allowed The specified operator is not permitted within an IL subexpression.
(impermissible are: JMP, RET, CAL, LDN, LD, TIME)
4204 Right parenthesis without left parenthesis. Insert left parenthesis, or delete right parenthesis.
4205 No comma permitted after ) Remove the comma behind the right parenthesis.
4206 No jump labels in subexpressions. Move the jump label outside the subexpression.
4207 N modifier requires a BOOL, BYTE, WORD or DWORD-type
operand. The N modifier requires a data type for which a Boolean negation can be performed.
4208 The expression in front of a conditional command must
return a BOOL-type result Ensure that the expression returns a Boolean result, or use a type conversion.
4209 Function names are not allowed here. Replace the function call with a variable or constant.
4210 CAL, CALC and CALN require a function block instance as
an operand Declare an instance of the function block to be called.
4211 Comments in IL at the end of the line only. Move the comment to the end of the line or into a separate line.
4212 Accumulator invalid before conditional instruction The accumulator content is not defined.
This is the case after instructions that do not return any result (CAL, for example).
4213 S and R require a BOOL-type operand Use a Boolean variable at this position.
4250 No correct start for an ST instruction The line does not start with a correct ST instruction.
4251 Function has too many parameters. More parameters were specified than were declared in the function definition.
4252 Function has insufficient parameters. Fewer parameters were specified than were declared in the function definition.
4253 IF and ELSIF require a Boolean expression as condition Ensure that the condition following an IF and ELSIF is a Boolean expression.
4254 WHILE requires a Boolean expression as condition Ensure that the condition following a WHILE is a Boolean expression.
4255 UNTIL requires a Boolean expression as condition Ensure that the condition following an UNTIL is a Boolean expression.
4256 NOT requires a Boolean operand. Ensure that the condition following a NOT is a Boolean expression.
4257 The counter of the FOR instruction must be INT-type Ensure that the counter variable is an integer or bitstring data type (DINT, DWORD, for
example).
4258 The counter in the FOR instruction is no write-accessible
variable Replace the counter variable with a write-accessible variable.
4259 The start value of the FOR instruction must be INT-type. The start value of the FOR instruction must be compatible with the counter variable type.
4260 The end value of the FOR instruction must be INT-type. The end value of the FOR instruction must be compatible with the counter variable type.
4261 The incrementation value of the FOR instruction must be
INT-type. The incrementation value of the FOR instruction must be compatible with the counter
variable type.
4262 EXIT is permitted only within a loop. Use EXIT only within FOR, WHILE or UNTIL instructions.
4263 Number, ELSE or END_CASE expected Only a number or an ELSE instruction, or the end instruction END_CASE, can be specified
within a CASE.
