Drive PLC Developer Studio
Working area
5-16
l
DDS EN 2.3
Export variable of object
The variables of the selected object are output to the symbol file. The other options take effect only
if this check box is ticked.
Export data entries
For structures and arrays of the object, entries are generated for access to the overall variables.
Export structure components
For object structures, a separate entry is generated for each variable component.
Export array entries
For object arrays, a separate entry is generated for each variable component.
Write access
The object variables may be modified via the OPC server.
Once the setting is effected for the current organization unit selection, another organization unit can
be selected and given different options.
OK
Using this button to close the dialog box means that all changes will be saved.
OptionsWMacros
Select the category Macros to open the following dialog box.
Name
Enter the name for the macro in this text box.
New
Press the button New to record the created macro.
Macro
This field lists all created macros. Highlighted macros can be deleted with the key.
Rename
Once an existing macro has been selected in the macro list, it can be renamed via dialog box Name.
Press the button Rename to rename the macro.
