Drive PLC Developer Studio
Visualization
9-8
l
DDS EN 2.3
9.2.8 Commands in the “Extras” menu
9.2.8.1 Element list
Icon: - Menu: Extras WElement list Keyboard: -
Use this command to open the dialog box Element list that lists all visualization elements with their
number, type and position.
•
The position refers to the X and Y position of the top left- and bottom right-hand corner of the
element.
•
Once one or several elements has/have been selected, the respective elements will be
highlighted in the visualization for a visual check, and the display may scroll to the section
with the selected elements as required.
Buttons
•
Use To the foreground to display the selected visualization elements in the foreground.
•
Use To the background to move the selected visualization elements to the background.
•
Use Delete to delete the selected visualization elements.
•
Use Undo and Redo to undo and redo actions carried out before. These commands are
analogous to Edit
➞ ➞ ➞ ➞Undo and Edit➞ ➞ ➞ ➞Redo. The editor window will display any changes.
•
Click OK to confirm the changes and close the dialog box.
9.2.8.2 To the foreground
Icon: - Menu: Extras WTo the foreground Keyboard: -
Use this command to bring the selected visualization elements to the front.
9.2.8.3 To the background
Icon: - Menu: Extras WTo the background Keyboard: -
Use this command to send the selected visualization elements to the back.
9.2.8.4 Align
Icon: - Menu: Extras WAlign Keyboard: -
Use this command to align several selected visualization elements.
The following alignment options are available:
Left All elements are aligned with their left-hand edge with the element on the extreme left.
Right / top / bottom Alignment analogous to Left.
Horizontal middle All elements are aligned by their horizontal centre within the centre of all elements.
Vertical middle All elements are aligned by their vertical centre within the centre of all elements.
9.2.8.5 Select all
Icon: - Menu: Extras WSelect all Keyboard: -
Use this command to select all visualization elements of the current visualization object.
