Drive PLC Developer Studio
Visualization
9-9
l
DDS EN 2.3
9.2.8.6 Placeholder list
Icon: - Menu: Extras WPlaceholder list Keyboard: -
Every point of the configuration dialog Extras
WConfigurethat allows variables or text to be input,
also offers the possibility of entering a placeholder instead of the variables or the text.
This is appropriate if the visualization object is to be integrated into other visualization objects as a
reference. On calling the respective reference, the placeholder can then be substituted accordingly
with the variable or text.
The dialog shows the placeholders used in the current visualization object and allows a preliminary
definition. The input focus must be on the visualization object.
On reference configuration, each placeholder can be substituted with the associated values.
Placeholders
This column lists the placeholders available for visualization.
Element numbers
Displays the number of the element for which the placeholder was generated. Also compare the
element list numbers.
Replacements
This option allows the input of a selection of strings which the placeholder substitutes. The
placeholder is the reference to the string. The strings must be comma-separated. Where no entry
exists, the placeholder can be substituted with any text during reference configuration.
Possible replacements
Placeholder Element number Replacements
text 0 box_a, box_b
Change colour 0 pic_prg.var, var_changecolour1, pic_prg.var_changecolour2
text2 1 a, b, c, d
togglevar 0
