XTC/3 Operating Manual
5.2.2.4.5 Standard Update Input Definition (XTC/3M only)
Command:
UI |
…
Input Number = 1-9 (255=All Inputs)
Input Definition= refer to section 5.2.2.3.5 on page 5-14
Response:
None (Just header and trailer)
5.2.2.4.6 Standard Update Output Definition (XTC/3M only)
Command:
UO
Output Number = 1-20 (255=All Outputs)
Output Definition = < Byte > refer to section 5.2.2.3.6 on page 5-15
Response:
None (Just header and trailer)
15
(0x0f)
RS232 Communi-
cations Protocol
0 = Standard RS232
1 = Datalog
2 = XTC/2
w/checksum
3 = XTC/2 no
checksum
Int 0 3
16 (0x10)
Auto Start Next Layer
(XTC/3M only)
1 = Yes, 0 = No
Int 0 1
Input Option
(XTC/3S only)
0 = Standard
1 = Film Select
255
(0xff)
1 All Parameters
(Must be in Ready)
1 Cannot change when a film is running.
Table 5-3 Standard general parameters (continued)
UG
(0x5547)
Command
ID
Name Units / Allowed
Values / Notes
Data
Type /
Format
Low
Limit
High
Limit
