XTC/3 Operating Manual
4.4.3.1 Remote Communication Parameters
RS-232
BAUD RATE. . . . . . . . . . . . . . . . . . . 9600, 19200, 38400, 57600, 115200
Press the TOGL key to move through the choices. Default is 115200
PROTOCOL RS232 . . . . . . . . . . . . . Standard, Datalog, XTC/2 Ck Sum,
XTC/2 No Ck Sum, XTC/C Ck Sum,
XTC/C No Ck Sum
Press the TOGL key to move through the choices. Default is Standard.
See
section 5.2 on page 5-6 .
Datalog returns response described under section 5.2.2.5 on page 5-29 , S19
command whenever the layer leaves the Deposit state.
See also
section 3.6.14, Datalog, on page 3-32 .
XTC/2 Ck Sum, XTC/C Ck Sum, see section 5.3.2 on page 5-37 .
XTC/2 No Ck Sum, XTC/C No Ck Sum, see section 5.3.3 on page 5-37 .
CAUTION
Upon changing the protocol to XTC/2 Ck Sum,
XTC/C Ck Sum, XTC/2 No Ck Sum, or XTC/C No Ck Sum,
it is highly recommended to check all prior parameters
entered to verify that they are compatible with the
reduced parameter set available in the XTC/2 protocols.
Otherwise, unexpected behavior may result.
Ethernet Interface Option
The optional TCP/IP interface supports static addresses; DHCP is not supported.
NOTE: IP address and net mask are initialized 1 minute after power-up. After this
time, they may be changed and XTC/3 must be power-cycled for the new
values to become active.
IP ADDRESS and NET MASK are 32 bit numbers, they are written out
as 4 8-bit numbers, separated by decimals.
IP ADDRESS . . . . . . . . . . . . . . . . . . nnn.nnn.nnn.nnn
Use the up and down cursor keys to scroll through the address and the numerics
keys to enter the desired address. The default address is 10.211.70.203.
NET MASK. . . . . . . . . . . . . . . . . . . . nnn.nnn.nnn.nnn
The net mask is some number of leading bits set to 1, followed by all 0.
The default net mask value is 255.255.0.0:
255 . 255 . 0 . 0
11111111 11111111 00000000 00000000
