318
Appendix
Other Parameters
No. Parameter name
Default value
(Reference)
Input range Unit Remarks
22 Control use region 0 0 ~ 99 0: J, 1: E, 2: EU
23 PSIZ command
function type
0 0 ~ 5 0: Maximum number of point data areas
1: Number of point data used
24 Local variable
number for storing
SEL-communication-
command return
code
99 1 ~ 99,
1001 ~ 1099
25~
29
(For extension) 0
30 Option Password 00 0H 0H ~
FFFFFFFFH
Reserved (Change prohibited)
* Change is prohibited unless instructed by the
manufacturer.
31 Option Password 01 0H 0H ~
FFFFFFFFH
Reserved (Change prohibited)
* Change is prohibited unless instructed by the
manufacturer.
32 Option Password 02 0H 0H ~
FFFFFFFFH
Reserved (Change prohibited)
* Change is prohibited unless instructed by the
manufacturer.
33~
35
(For extension) 0
36 PC/TP data protect
setting (Program)
0H 0H ~
FFFFFFFFH
Bits 0 to 3: Protect type (0: Read/write, 1: Read only,
2: No read/write)
Bits 4 to 7: Protect release method (0: Special
operation)
Bits 8 to 11: Protect range maximum number (1’s place,
BCD)
Bits 12 to 15: Protect range maximum number (10’s
place, BCD)
Bits 16 to 19: Protect range minimum number (1’s place,
BCD)
Bits 20 to 23: Protect range minimum number (10’s
place, BCD)
* Referenced by the PC/TP (PC software version
2.0.0.42 or later and TP application version 1.09 or
later)
37 PC/TP data protect
setting (Position)
0H 0H ~
FFFFFFFFH
Bits 0 to 3: Protect type (0: Read/write, 1: Read only,
2: No read/write)
Bits 4 to 7: Protect release method (0: Special
operation)
Bits 8 to 11: Protect range maximum number (10’s
place, BCD)
Bits 12 to 15: Protect range maximum number (100’s
place, BCD)
Bits 16 to 19: Protect range maximum number (1000’s
place, BCD)
Bits 20 to 23: Protect range minimum number (10’s
place, BCD)
Bits 24 to 27: Protect range minimum number (100’s
place, BCD)
Bits 28 to 31: Protect range minimum number (1000’s
place, BCD)
* The value in the 1’s place is considered “0” for both
the protect range maximum/minimum numbers.
* Referenced by the PC/TP (PC software version
2.0.0.42 or later and TP application version 1.09 or
later)
