146
Part 4 Commands
 SLTL (Select tool coordinate system)
Extension condition
(LD, A, O, AB, OB)
Input condition
(I/O, flag)
Command, declaration
Output
(Output, flag)
Command,
declaration
Operand 1 Operand 2
Optional Optional SLTL
Tool coordinate
system number
Prohibited CP
[Function] Set the value specified in operand 1 as the selected tool coordinate system number.
Refer to 3, "Coordinate System," in Chapter 3 of Part 4.
(Note 1) The number declared last in the system becomes valid.
The selected tool coordinate system number will remain valid after the program ends, or even
after reconnection of power if a system-memory backup battery is installed.
(Note 2) Only one tool coordinate system number can be selected in the system.
(Note 3) Expressly declare SLTL in the program to prevent problems that may occur when the
coordinate system number changed via the PC software or teaching pendant was not
returned to the original setting.
(Set SLCT = 0, if tool coordinate system is not used.)
