PAPER FACTS
XEROX DOCUPRINT 180 LPS OPERATOR GUIDE 3-19
Stacker bins
The Xerox DocuPrint 180 LPS can have up to four high-capacity
stacker (HCS) bins. (Refer to the “System overview of the Xerox
DocuPrint 180 LPS” chapter for additional information on the high-
capacity stacker bins.)
• You can lower, pull out, and unload any bin not currently in use,
without interrupting printing, as long as another HCS is ready to
receive paper.
•
If you select a bin that is in use, the printer begins stacking in
the next defined high-capacity stacker bin if it is available. If no
stacker bin is available, printing stops.
• Once a sheet is delivered to a stacker bin, each subsequent
sheet must be within 25 mm of each dimension of the first
sheet.
Refer to table 3-6 for additional information on performance of the
high-capacity stacker bins.
Table 3-6. Stacker bin performance guide
Paper Superior performance Good performance
Performance limits and
suggested alternatives
Size range
1
8 by 10 to 11.69 by 17
inches/203 by 254 to 297 by
432 mm Smaller or larger sizes cannot be
used.
Weight range 20 to 110 pounds/80 to 200
gsm
Lighter than 20 pounds/80
gsm and no lighter than 16
pounds/60 gsm Weights outside the limits shown
here are not recommended.
Capacity
•
Capacity automatically
limited so stack weight will
not exceed 30 lbs/13.g kg
• Selectable with bin capacity
programming (Refer to the
“Bin full criteria and setting
bin limits” section of the
“Status and print tasks”
chapter for instructions.
Stack quality
•
Xerographic paper in
good condition
• 20 pound/80 gsm and
heavier stock
• Very low to no output
curl
•
Lighter weight stocks
with low output curl
• Intermixed stocks
•
Adjust process decurler
•
Flip paper in paper feeders
• Limit stack capacity to
acceptable limits.
