STATUS AND PRINT TASKS
XEROX DOCUPRINT 180 LPS OPERATOR GUIDE 9-5
Note: When various sized paper is stacked in a bin, the
size displayed indicates the largest paper width and length.
•
Stacker bin levels. The levels depicted indicate:
— Empty
— 1 ream
— 2 reams
— 3 reams
— 4 reams
— Full.
• Output bin mode. The mode is either:
— Auto. When the first bin is full, stacking automatically
switches to the next bin.
— Separate. The report switches to the next bin at the report
boundary.
Note: The Output Bin mode displays on the bin that is currently
in use.
Note the following:
• You can also access the Printer Status window (PC UI) or
display by pressing the key.
• The printer control console also provides a mimic of the printer
showing some of the same information specified in this section.
•
If you have the system controller terminal, or are running print
jobs using command files, you will not see all of the information
listed in the previous section.
