HIP PRINTING TASKS
XEROX DOCUPRINT 180 LPS OPERATOR GUIDE 8-5
HP1320 FUNCTION IS NOT SUPPORTED BY CURRENT HOST
HP2320 INVALID COMMAND WITH CURRENT HOST TYPE
HP2330 INVALID COMMAND WITH NO HOST SPECIFIED
Select a communication mode
Use this task to select the HIP communication mode to use.
Note: This task is not necessary if your LPS has only one host.
Select a Communication Mode task
through windows
From the HIP window, select the mode you want from the Host field’s
auxiliary menu.
Select a Communication Mode task
through command line
Enter the following command:
HIP HOST XPF
HIP must be offline to change from one host to another. If the system
is not offline or is not idle, the command is rejected and one or more
of the following messages appears:
HP2020 SELECTED HOST NOT PRESENT ON SYSTEM
HP2400 HIP INTERFACE MUST BE OFFLINE. ENTER ’HIP
OFFLINE’.
HP7100 CANNOT CHANGE HOSTS WHILE JOBS ARE PENDING
OR ACTIVE.
Place HIP online
Use this task to place the LPS online to the host.
Place HIP Online task through windows Select the Online header button from the HIP window.
Place HIP Online task through
command line
Select the Online header button from the HIP window.
Enter the following command:
HIP ONLINE [ALL]
The ALL parameter specifies that both print and nonprint files are
accepted. The default is that only print files are accepted. As print
jobs are received, they are entered into HIP’s internal job queue and
become eligible for submission to Operator Communications
Subsystem (OCS) for printing. One of the following messages
appears:
HP1210 HOST ONLINE. ACCEPTING ALL JOBS
HP1220 HOST ONLINE. ACCEPTING PRINT JOBS ONLY
HP2010 NO HOST SELECTED
HP2030 ALL NOT ALLOWED AT CURRENT LOGON LEVEL
HP0200 FAILED TO GO ONLINE
Note: ONLINE ALL is accepted in logon level class 2 and above for
all hosts
