SYSTEM OVERVIEW OF THE XEROX DOCUPRINT 180 LPS

1-2

XEROX DOCUPRINT 180 LPS OPERATOR GUIDE

Base components

The base components of the Xerox DocuPrint 180 LPS are the
system controller and the printer, shown in figure 1-1.

Figure 1-1.

Base components

1

System controller

2 Printer

Note:

Figure 1-1 shows one of the Xerox DocuPrint 180

configuration options. For information on the various Xerox
DocuPrint 180 configurations, refer to the “Optional components”
section later in this chapter.
