SYSTEM OVERVIEW OF THE XEROX DOCUPRINT 180 LPS
XEROX DOCUPRINT 180 LPS OPERATOR GUIDE 1-13
Optional components
Optional components are available for both the system controller and
the printer.
Optional system controller components
The optional components for the system controller are as follows:
•
Peripheral cabinet
•
Open-reel tape drive
• 18/36 track cartridge tape drive
• Floppy disk drive.
Peripheral cabinet
The peripheral cabinet houses the open-reel and 18/36 track tape
drives. Both drives are shown in figure 1-11.
Figure 1-11. Peripheral cabinet with tape drives
1 Open-reel tape drive
2 18/36 track cartridge tape drive
Open-reel tape drive
The open-reel tape drive has the following features:
•
1/2 inch/13 mm streamer with a horizontal tape path.
• Self-loading tape system.
• Tape is visible through a window in the front of the tape drive so
you can verify the presence of the tape and tape motion.
•
The tape cover can be raised for routine cleaning.
•
It has a control panel including an eight-character alphanumeric
display for messages and error information. Figure 1-12 shows
the control panel.
