STATUS AND PRINT TASKS
XEROX DOCUPRINT 180 LPS OPERATOR GUIDE 9-7
Printer Status task through
command line
Enter the following command:
PSTATUS
If you have the PC UI and are not currently running print jobs using
command files, the Printer Status window appears. Otherwise, the
selection and status information appears in the Messages window
(PC UI) or on the terminal screen. Figure 9-3 shows an example of
HIP job status display.
Figure 9-3. Example of HIP job status display
Note: When there is information about which you should be
specifically aware, that information flashes on the display. For
example, if you had keyed in SEL AUTO when one of the stacker
trays is not empty, the message EMPTY ME flashes instead of the
READY message.
IOT State: Client-layer:
Current feed mode: feed mode
Current select mode: select mode
Tray: Status: Paper level: Paper size:
1 Selected 1/2 full 11.5 by 8.0
2 Ready Full 11.5 by 8.0
3 Ready Full 11.5 by 8.0
4 Ready 1/4 full 14.0 by 11.5
5 Ready full 11.5 by 8.0
6 Ready full 11.5 by 8.0
Bin: Status: Paper level: Paper size:
A Selected 1/2 full 8.5 by 11.00
B Ready Empty 8.5 by 11.00
C Ready Unavailable Unavailable
D Ready Empty Empty
