JOB CONTROL TASKS
XEROX DOCUPRINT 180 LPS OPERATOR GUIDE 5-7
Align
Use this task to align the laser image of the printer with the paper.
Note: Normal alignment on the LPS is exceptionally accurate and
very seldom, if ever, requires adjustment. If you need to adjust the
alignment for a specific form, it is very important to remember to
restore the alignment to the original specifications when the job is
completed. Failure to do so could result in lost information when
printing future jobs. (The normal alignment setting of the Xerox
DocuPrint 180 LPS is 1,0.)
Align task through windows Perform the following steps:
Step 1. Select “Align” from the Job Control menu to open the Align window
(see figure 5-4).
Figure 5-4. Align window
The Align window displays the current alignment.
The paper icons displayed underneath the Lines and Dots fields
show the direction the image moves on the paper if you change the
numeric value in the fields.
“-” is the direction the image moves if you decrease the number in the
field.
“+” is the direction the image moves if you increase the number in the
field
Step 2. To change the alignment, enter a new value in the Lines and/or Dots
field(s).
