MAINTENANCE TASKS
11-8 XEROX DOCUPRINT 180 LPS OPERATOR GUIDE
Step 3. Grasp the green handle on the fuser drawer and pull it out until it
stops (see figure 11-10).
Figure 11-10.Opening the fuser drawer
Step 4. Locate the fuser agent reservoir (see figure 11-11).
Figure 11-11.Locating the fuser agent reservoir
Step 5. Pull the fuser agent reservoir out until it stops.
Step 6. Remove the reservoir cap by turning it counterclockwise.
Step 7. Remove the cap from a new bottle of fuser agent.
!
Warning: If any fuser agent spills on the floor, remove it
immediately. Fuser agent spills make the floor slippery.
