SYSTEM CONTROL TASKS
XEROX DOCUPRINT 180 LPS OPERATOR GUIDE
4-23
Stopping the printing of a console log
To stop the printing of a console log, select the Stop Print header
button. If the console log has already started printing, use the
Saving the current console log
To save the current console log:
Step 1.
Select the “Save” option from the header auxiliary menu of the
Console Log window to open the Save window (see figure 4-19).
Figure 4-19. Save window
Step 2.
Enter a file name for the console log in the Save Console Log as field.
Note:
The file name can be up to eight characters in length,
and can consist of letters or numbers. Punctuation characters
(such as a comma) or spaces should not be used in the name.
Step 3.
Select either:
•
Hard Disk. Save the console log on the system disk.
•
Floppy. Save the console log on a formatted floppy disk.
Step 4.
Select either:
•
Apply/Close. Save the file and close the window.
•
Close. Cancel the save request and close the window.
Note:
If the PC UI cannot save the whole console log due
to insufficient space, an error message displays and no
entry is saved.
