STATUS AND PRINT TASKS
9-22 XEROX DOCUPRINT 180 LPS OPERATOR GUIDE
Purge feed
Use the Purge Feed task to specify which feeder trays you want to
supply the LPS with purge sheets.
Note: In order to clean the photoreceptor properly following a fuser
area jam, one of the feeder trays you specify must contain paper at
least as long as the paper used in the current print job.
Note:
Do not specify a tray containing ordered stock.
Purge Feed task through windows Through windows:
1. Select the “Purge Feed” option from the header auxiliary menu
of the Printer Status window to open the Purge Feed window
(see figure 9-11).
Figure 9-11. Purge Feed window
Select the checkbox of any tray you want the LPS to use for
purge sheets. Tray 2 is the default selection of this window.
2. Select either:
•
Apply/Close. Apply you selection and close the window.
•
Close. Close the window.
Purge Feed task through command line To specify trays for purge feeding, enter the following command:
PFEED [tray list]
Table 9-4 lists the parameter and its description.
To display the currently assigned purge feed trays, enter the
following command:
PFEED
Table 9-4. PFEED command parameter and description
Parameter Description
tray list The numbers of the trays you want the LPS to
use for purge sheets.
