PROBLEM SOLVING TASKS
XEROX DOCUPRINT 180 LPS OPERATOR GUIDE 12-3
Printing problems
When prints are skewed or damaged, follow these steps to adjust the
registration transport roll levers (heavy paper levers):
Prints are skewed or damaged
To correct this problem, adjust the registration transport roll levers
(heavy paper levers) in the following way:
Step 1. Open the right and left doors of the printer and locate the heavy paper
levers. (They are located behind area 4 and area 2.)
Step 2. Pull the levers forward (toward you) on the silver latch release.
Step 3. Turn both levers to the left (counter clockwise), as illustrated in figure
12-2.
Figure 12-2. Locating the two heavy weight levers
