USING THE PC UI
XEROX DOCUPRINT 180 LPS OPERATOR GUIDE 2-21
Scrolling text to the left To scroll text to the left, follow the above procedure, but place the
cursor on the arrow right target area. A single click moves the
information one character to the left.
Figure 2-15. Scrolling the text horizontally
Activating an open window
Only one window can be active at a time, although more than one
window can be open at a time. To activate an open window, move the
cursor into the work area of the window and click once with the left
mouse button. The header area of the window is now highlighted,
and you can select options or enter commands in the window. If the
window was underneath another window on the desktop, it now
appears on top.
Note: To activate a Menu window, click once on a Move/Resize
target, rather than the work area of the window.
Performing operator tasks through the PC UI
The PC UI gives you two options for performing operator tasks:
•
Selecting tasks through windows
•
Entering commands through the Messages window.
Performing tasks through windows
Follow the procedures outlined earlier in this chapter to open Menu
and Task windows and select options using the PC UI windows.
