E6581301
D-1
4
4. Searching and setting parameters
There are two types of setting mode quick mode and standard setting mode.
Quick mode : EASY Key: ON
Eight frequently used basic parameters are just displayed
(Factory default position).
Quick mode (EASY)
Title Function
CW Automatic function setting
RV
V/f control mode selection
HJ Maximum frequency
CEE Acceleration time 1
FGE
Deceleration time 1
VJT
Motor overload protection level 1
HO FM terminal meter adjustment
RUGN Registered parameter display selection
Parameters you selected can be displayed by changing
the parameter. (Up to 32 parameters)
Standard setting mode : EASY Key: OFF
Both basic and extended all parameters are displayed.
Basic parameters : This parameter is a basic parameter for the
operation of the inverter.
⇒ For details of basic parameters, refer to Section 5.
⇒ For parameter settings, refer to Section 11.
Extended parameters :The parameters for detailed and special
setting.
⇒ For details of extended parameters, refer to Section 6.
⇒ For parameter settings, refer to Section 11.
For reasons of safety, the following parameters have been set up so that they cannot be reprogrammed while the
inverter is running.
[Basic parameters]
CW
(Automatic acceleration/deceleration)
CW (Automatic torque boost)
CW (Automatic function setting)
EOQF (Command mode selection)
HOQF (Frequency setting mode selection 1)
RV (V/f control mode selection)
XN (Base frequency 1)
XNX (Base frequency voltage 1)
HJ (Maximum frequency)
WXU (Auto-restart control selection)
WXE (Regenerative power ride-through control)
RD (Dynamic braking selection)
RDT (Dynamic braking resistance)
RDER (Allowable continuous braking resistance)
V[R (Factory default setting)
⇒ To write-protect extended parameters during operation, refer to Section 11.
