■ Selection of braking resistor option and braking unit
Standard braking resistors are listed in the table below.
The usage rate is 3%. (Except for type DGP***)
Braking resistor
Inverter type Model number
[Note 2]
Rating
Continuous regenerative
braking allowable capacity
[Note 1]
VFAS1-2004PL,
2007PL
PBR-2007 120W -200Ω 48W
VFAS1-2015PL,
2022PL
PBR-2022 120W -75Ω 48W
VFAS1-2037PL PBR-2037 120W - 40Ω 48W
VFAS1-2055PL PBR3-2055 240W - 20Ω 96W
VFAS1-2075PL PBR3-2075 440W -15Ω 130W
VFAS1-2110PM PBR3-2110 660W -10Ω 200W
VFAS1-2150PM,
2185PM
PBR3-2150 880W -7.5Ω 270W
VFAS1-2220PM PBR3-2220 1760W -3.3Ω 610W
VFAS1-2300PM PBR3-2220 1760W - 3.3Ω 610W
VFAS1-2370PM
~2550P
PBR-222W002 2200W - 2Ω 1000W
VFAS1-2750P DGP600W-B1 3.4kW - 1.7Ω 3400W
VFAS1-4007PL
~4022PL
PBR-2007 120W - 200Ω 48W
VFAS1-4037PL PBR-4037 120W -160Ω 48W
VFAS1-4055PL PBR3-4055 240W - 80Ω 96W
VFAS1-4075PL PBR3-4075 440W -60Ω 130W
VFAS1-4110PL PBR3-4110 660W - 40Ω 190W
VFAS1-4150PL,
4185PL
PBR3-4150 880W -30Ω 270W
VFAS1-4220PL PBR3-4220 1760W - 15Ω 540W
VFAS1-4300PL PBR3-4220 1760W- 15Ω 540W
VFAS1-4370PL
~4750PL
PBR-417W008 1760W -8Ω 1000W
VFAS1-4900PC
~4160KPC
DGP600W-B2 7.4kW - 3.7Ω 7400W
VFAS1-4200KPC,
4220KPC
[Note 3]
PB7-4220K
+
DGP600W-B3
8.7kW -1.9Ω 8700W
VFAS1-4280KPC [Note 3]
PB7-4220K
+
DGP600W-B4
14kW - 1.4Ω 14000W
VFAS1-4355KPC
VFAS1-4400KPC
VFAS1-4500KPC
Note 1: Continuous regenerative braking allowable capacities vary according to the rated capacity and resistance of
the resistor for reasons of endurance.
Note 2: PBR- , PBR3- and DGP600W-B : Braking resistor (Connected to PA/+, PB terminal)
Note 3: PB7-4 : Braking unit (Connected to PA/+, PC/- terminal)
Combined braking resistor (Connected to PA/+, PB terminal of PB7-4 )
