K-24
E6581301
11
[24] Protection functions [3/3]
Vector control
Title
Communi
cation
No.
Function Adjustment range
Minimum
setting unit
(Panel/Communi
cation)
Default
setting
Write during
running
Speed
control
Torque
control
PM
control V/f Constant Reference
H 0637 PTC1 thermal selection
0:Deselect
1:Select
1/1 0 Disabled ●/● ●/● ● ● *1
H 0638 PTC2 thermal selection
0:Deselect
1:Select
1/1 0 Disabled ●/● ●/● ● ● *1
H 0639
Braking resistance overload time
(10 times of rated torque)
0.1~600.0 sec. 0.1/0.1 5.0 Disabled ●/● ●/● ● ● 5. 19
H 0640
Step-out detection current level
(for PM motors)
10~150 1/1 100 Disabled - - - - 6. 29
H 0641
Step-out detection time (for PM
motors)
0.0:Not detect
0.1~25.0
0.1/0.1 0.0 Disabled - - - - 6. 29
*1: ⇒ For details, refer to Instruction Manual (E6581339) specified in Section 6.41.
[25] Override
Vector control
Title
Communi
cation
No.
Function Adjustment range
Minimum
setting unit
(Panel/Communi
cation)
Default
setting
Write during
running
Speed
control
Torque
control
PM
control V/f Constant Reference
H 0660 Override addition input selection
0:Disabled
1:VI/II (voltage/current input)
2:RR/S4 (potentiometer/voltage input)
3:RX (voltage input)
4:Operation panel input enabled (including
LED/LCD option input)
5:2-wire RS485 input enabled
6:4-wire RS485 input enabled
7:Communications option input enabled
8:Optional AI1 (differential current input)
9:Optional AI2 (voltage/current input)
10:UP/DOWN frequency
11:Optional RP pulse input
12:Optional high-speed pulse input
13:Optional binary/BCD input
1/1 0 Enabled ●/● - ● ● 6. 34
H 0661
Override multiplication input
selection
0:Disabled, 1:VI/II, 2:RR/S4, 3:RX, 4:H,
5:Optional AI1
1/1 0 Enabled ●/● - ● ● 6. 34
H 0669
Logic output/pulse output
selection (OUT1)
0:Logic output
1:Pulse output
1/1 0 Disabled ●/● ●/● ● ● 6. 35. 1
COUN 0670 AM terminal meter selection 0~64 *1 1/1 2 Enabled ●/● ●/● ● ● 5. 16
This parameter moves to a fundamental parameter.
*1: ⇒ For the adjustment range, see the table on page K-39.
Sensorless vector/vector with sensor (●:Effective, -:Ineffective)
Sensorless vector/vector with sensor (●:Effective, -:Ineffective)
