Toshiba Tosvert VF-AS1 - Manual (Page 254)

K-16
E6581301
11
[18] Motor constant [2/2]
Vector control
Title
Communi
cation
No.
Function Adjustment range
Minimum
setting unit
(Panel/Communi
cation)
Default
setting
Write during
running
Speed
control
Torque
control
PM
control V/f Constant Reference
H 0401 Slip frequency gain 0~150% 1/1 70 Enabled ●/● - - - 6. 22
H 0402 Auto-tuning 2
0:No tuning
1:Self-cooled motor tuning
2:Forced air-cooled motor tuning
1/1 0 Disabled ●/● ●/● - - 6. 22
H 0405
Motor rated capacity (motor name
plate)
0.10~500.0kW 0.01/0.01 *1 Enabled ●/● ●/● - - 6. 22
H 0406
Motor rated current (motor name
plate)
0.1~2000A 0.1/0.1 *1 Disabled ●/● ●/● - - 6. 22
H 0407
Motor rated revolutions (motor name
plate)
100~60000min-1 1/1 *1 Disabled ●/● ●/● - - 6. 22
H 0410 Motor constant 1 (torque boost) 0.0~30.0% 0.1/0.1 *1 Enabled ●/● ●/● - - 6. 22
H 0411 Motor constant 2 (no load current) 10~90% 1/1 *1 Disabled ●/● ●/● - - 6. 22
H 0412 Motor constant 3 (leak inductance) 0~200% 0.1/0.1 *1 Disabled ●/● ●/● - - 6. 22
H 0413 Motor constant 4 (rated slip) 0.1~25.0% 0.1/0.1 *1 Enabled ●/● ●/● - - 6. 22
H 0415
Exciting strengthening
coefficient
100~130% 1/1 100 Disabled ●/● ●/● - - 6. 23
H 0416 Stall prevention factor 10~250 1/1 100 Disabled ●/● ●/● - - 6. 23
*1: Default values vary depending on the capacity. ⇒ See the table of K-46.
[19] Torque control [1/2]
Vector control
Title
Communi
cation
No.
Function Adjustment range
Minimum
setting unit
(Panel/Communi
cation)
Default
setting
Write during
running
Speed
control
Torque
control
PM
control V/f Constant Reference
H 0420 Torque command selection
1:VI/II (voltage/current input)
2:RR/S4 (potentiometer/voltage input)
3:RX (voltage input)
4:Operation panel input enabled (including
LED/LCD option input)
5:2-wire RS485 communication input
6:4-wire RS485 communication input
7:Communications option input enabled
8:Optional AI1 (differential current input)
1/1 3 Enabled - ●/● - - *1
H 0423
Tension torque bias input
selection (torque control)
0:Disabled, 1~8 (same as H) 1/1 0 Enabled - ●/● - - 6. 24. 3
H 0424
Load sharing gain input
selection
0:Disabled, 1~8 (same as H) 1/1 0 Enabled - ●/● - - 6. 24. 3
*1: ⇒ For details, refer to Instruction Manual (E6581331) specified in Section 6.41.
Sensorless vector/vector with sensor (●:Effective, -:Ineffective)
Sensorless vector/vector with sensor (●:Effective, -:Ineffective)
