[3] Terminal function selection
Vector control
Title
Communi
cation
No.
Function
Adjustment range
Minimum
setting unit
(Panel/Communi
cation)
Default
setting
Write during
running
Speed
control
Torque
control
PM
control
V/f
Reference
H
0110
Always ON function selection 1
0~135 *1
1/1
*3
Disabled
●/●
●/●
●
●
6. 3. 1
H
0111
Input terminal function selection 1 (F) 0~135 *1
1/1
2
Disabled
●/●
●/●
●
●
7. 2. 1
H
0112
Input terminal function selection 2 (R) 0~135 *1
1/1
4
Disabled
●/●
●/●
●
●
7. 2. 1
H
0113
Input terminal function selection
3 (ST)
0~135 *1
1/1
6
Disabled
●/●
●/●
●
●
7. 2. 1
H
0114
Input terminal function selection
4 (RES)
0~135 *1
1/1
8
Disabled
●/●
●/●
●
●
7. 2. 1
H
0115
Input terminal function selection
5 (S1)
0~135 *1
1/1
10
Disabled
●/●
●/●
●
●
7. 2. 1
H
0116
Input terminal function selection
6 (S2)
0~135 *1
1/1
12
Disabled
●/●
●/●
●
●
7. 2. 1
H
0117
Input terminal function selection
7 (S3)
0~135 *1
1/1
14
Disabled
●/●
●/●
●
●
7. 2. 1
H
0118
Input terminal function selection
8 (RR/S4)
0~135 *1
1/1
72
Disabled
●/●
●/●
●
●
7. 2. 1
H
0119
Input terminal function selection
9 (LI1)
0~135 *1
1/1
0
Disabled
●/●
●/●
●
●
7. 2. 1
H
0120
Input terminal function selection
10 (LI2)
0~135 *1
1/1
0
Disabled
●/●
●/●
●
●
7. 2. 1
H
0121
Input terminal selection 11 (LI3) 0~135 *1
1/1
0
Disabled
●/●
●/●
●
●
7. 2. 1
H
0122
Input terminal selection 12 (LI4) 0~135 *1
1/1
0
Disabled
●/●
●/●
●
●
7. 2. 1
H
0123
Input terminal selection 13 (LI5) 0~135 *1
1/1
0
Disabled
●/●
●/●
●
●
7. 2. 1
H
0124
Input terminal selection 14 (LI6) 0~135 *1
1/1
0
Disabled
●/●
●/●
●
●
7. 2. 1
H
0125
Input terminal selection 15 (LI7) 0~135 *1
1/1
0
Disabled
●/●
●/●
●
●
7. 2. 1
H
0126
Input terminal selection 16 (LI8) 0~135 *1
1/1
0
Disabled
●/●
●/●
●
●
7. 2. 1
H
0127
Always ON function selection 2
0~135 *1
1/1
0
Disabled
●/●
●/●
●
●
6. 3. 1
H
0128
Always ON function selection 3
0~135 *1
1/1
0
Disabled
●/●
●/●
●
●
6. 3. 1
H
0130
Output terminal function
selection 1 (OUT1)
0~255 *2
1/1
4
Disabled
●/●
●/●
●
●
7. 2. 2
H
0131
Output terminal function
selection 2 (OUT2)
0~255 *2
1/1
6
Disabled
●/●
●/●
●
●
7. 2. 2
H
0132
Output terminal function
selection 3 (FL)
0~255 *2
1/1
10
Disabled
●/●
●/●
●
●
7. 2. 2
H
0133
Output terminal function
selection 4 (OUT3)
0~255 *2
1/1
254
Disabled
●/●
●/●
●
●
7. 2. 2
H
0134
Output terminal function
selection 5 (OUT4)
0~255 *2
1/1
254
Disabled
●/●
●/●
●
●
7. 2. 2
H
0135
Output terminal function
selection 6 (R1)
0~255 *2
1/1
254
Disabled
●/●
●/●
●
●
7. 2. 2
H
0136
Output terminal function
selection 7 (OUT5)
0~255 *2
1/1
254
Disabled
●/●
●/●
●
●
7. 2. 2
H
0137
Output terminal function
selection 8 (OUT6)
0~255 *2
1/1
254
Disabled
●/●
●/●
●
●
7. 2. 2
H
0138
Output terminal function
selection 9 (R2)
0~255 *2
1/1
254
Disabled
●/●
●/●
●
●
7. 2. 2
*1:
⇒ For the adjustment range, see the table on page K-41. *2: ⇒ For the adjustment range, see the table on page K-43. *3: Inverter with a model number ending with -WN: 0 -WP: 6
Sensorless vector/vector with sensor (●:Effective, -:Ineffective)
