Toshiba Tosvert VF-AS1 User Manual

Page 186

E6581301

F-74

■

Trace data communication number

Communication

No.

Function

Minimum setting

/readout unit

Setting/readout range

Default setting

E000

Trace data 1 pointer
(For H)

~ (correspond to E100

to E199)

E001

Trace data 2 pointer
(For H)

~ (correspond to E200

to E299)

E002

Trace data 3 pointer
(For H)

~ (correspond to E300

to E399)

E003

Trace data 4 pointer
(For H)

~ (correspond to E400

to E499)

E100

Data 1 of trace data 1

~HHHH

Data 2~99 of trace data 1

~HHHH

E199

Data 100 of trace data 1

~HHHH

E200

Data 1 of trace data 2

~HHHH

Data 2~99 of trace data 2

~HHHH

E299

Data 100 of trace data 2

~HHHH

E300

Data 1 of trace data 3

~HHHH

Data 2~99 of trace data 3

~HHHH

E399

Data 100 of trace data 3

~HHHH

E400

Data 1 of trace data 4

~HHHH

Data 2~99 of trace data 4

~HHHH

E499

Data 100 of trace data 4

~HHHH

Communication numbers E000 to E003 are automatically incremented by the inverter when data is traced
continuously.
* In ordinary cases, these parameters do not need to be rewritten.

Ex.) When operation frequency data is acquired through a communication device
Data acquired

(H) h=8000

⇒ 8000×0.01Hz=80.0Hz
