- Contents -
I. Safety precautions 1
I I. Introduction 7
1. Read first A-1
1.1 Check product purchase A-1
1.2 Contents of the product A-1
1.3 Structure of the main body A-2
1.3.1 Names and functions A-2
1.3.2 Detaching the cover A-9
1.3.3 Grounding capacitor switching method A-12
1.4 Notes on the application A-14
1.4.1 Motors A-14
1.4.2 Inverters A-16
1.4.3 What to do about the leak current A-17
1.4.4 Installation A-19
2. Connection equipment B-1
2.1 Cautions on wiring B-1
2.2 Standard connections B-3
2.3 Description of terminals B-8
2.3.1 Main circuit terminals B-8
2.3.2 Control circuit terminals B-9
2.3.3 Serial RS485 communication connector B-14
3. Operations C-1
3.1 Setting/monitor modes C-2
3.2 Simplified operation of the VF-AS1 C-3
3.2.1 Terminal board operation C-3
3.2.2 Panel operation C-7
4. Searching and setting parameters D-1
4.1 How to set parameters D-2
4.1.1 Setting parameters in the quick mode D-2
4.1.2 Setting parameters in the standard setting mode D-3
4.2 Functions useful in searching for a parameter or changing a parameter setting D-4
5. Basic parameters E-1
5.1 History function E-1
5.2 Setting acceleration/deceleration time E-2
5.2.1 Automatic acceleration/deceleration E-2
5.2.2 Manually setting acceleration/deceleration time E-3
5.3 Increasing starting torque E-3
5.4 Setting parameters by operating method E-5
5.5 Selection of operation mode E-6
5.6 Selecting control mode E-11
5.7 Manual torque boost–increasing torque boost at low speeds E-15
5.8 Base frequency E-15
5.9 Maximum frequency E-16
5.10 Upper limit and lower limit frequencies E-16
5.11 Setting frequency command characteristics E-17
5.12 Preset speed operation (speeds in 15 steps) E-17
5.13 Selecting forward and reverse runs (operation panel only) E-20
5.14 Setting the electronic thermal E-21
5.15 Changing the display unit % to A (ampere)/V (volt) E-25
5.16 Meter setting and adjustment E-26
