Toshiba Tosvert VF-AS1 User Manual
Page 267
K-29
E6581301
11
[28] Communication function [1/4]
Vector control
Title
Communi
cation
No.
Function
Adjustment range
Minimum
setting unit
(Panel/Communi
cation)
Default
setting
Write during
running
Speed
control
Torque
control
PM
control V/f Constant Reference
H
0800
Baud rate (2-wire RS485)
0:9600 bps, 1:19200 bps, 2:38400 bps
1/1
1
Enabled
●/●
●/●
●
●
6. 38. 1
H
0801
Parity (common to 2-wire RS485
and 4-wire RS485)
0:Non parity, 1:Even parity,
2:Odd parity
1/1
1
Enabled
●/●
●/●
●
●
6. 38. 1
H
0802
Inverter number (common)
0~247
1/1
0
Enabled
●/●
●/●
●
●
6. 38. 1
H
0803
Communications time-out time
(common to 2-wire RS485 and
4-wire RS485)
0:OFF, 1~100 sec.
1/1
0
Enabled
●/●
●/●
●
●
6. 38. 1
H
0804
Communications time-out action
(common to 2-wire RS485 and
4-wire RS485)
0~8
1/1
8
Enabled
●/●
●/●
●
●
6. 38. 1
H
0805
Send waiting time (2-wire
RS485)
0.00:Default, 0.01~2.00 sec.
0.01/0.01
0.00
Enabled
●/●
●/●
●
●
6. 38. 1
H
0806
Inverter-to-inverter
communications (common to 2-
wire RS485)
0:Slave (issues a 0Hz command if something
goes wrong with the master)
1:Slave (continues operation if something goes
wrong with the master)
2:Slave (trips for emergency stop if something
goes wrong with the master)
3:Master (sends a frequency command)
4:Master (sends an output frequency)
5.Master (sends a torque command)
6.Master (sends an output torque command)
1/1
0
Enabled
●/●
●/●
●
●
6. 38. 1
H
0807
Protocol selection (2-wire
RS485)
0:TOSHIBA
1:MODBUS
1/1
0
Enabled
●/●
●/●
●
●
6. 38. 1
H
0810
Frequency point selection
0:Disabled
1:2-wire RS485
2:4-wire RS485
3:Communication add option
1/1
0
Enabled
●/●
-
●
●
6. 38. 1
H
0811
Point 1 setting
0-100%
1/1
0
Enabled *2
●/●
-
●
●
6. 38. 1
H
0812
Point 1 frequency
0.0~HJ Hz
0.1/0.01
0.0
Enabled *2
●/●
-
●
●
6. 38. 1
H
0813
Point 2 setting
0~100%
1/1
100
Enabled *2
●/●
-
●
●
6. 38. 1
H
0814
Point 2 frequency
0.0~HJ Hz
0.1/0.01
*1
Enabled *2
●/●
-
●
●
6. 38. 1
H
0820
Communication speed (4-wire
RS485)
0:9600 bps, 1:19200 bps, 2:38400 bps
1/1
1
Enabled
●/●
-
●
●
6. 38. 1
H
0825
Send waiting time (4-wire
RS485)
0.00:Default, 0.01~2.00 sec.
0.01/0.01
0.00
Enabled
●/●
●/●
●
●
6. 38. 1
Sensorless vector/vector with sensor (●:Effective, -:Ineffective)
*1: Inverter with a model number ending with -WN: 60.0 -WP: 50.0
*2:
Effective when a command value is sent by communication.
