Toshiba Tosvert VF-AS1 - Manual (Page 252)

K-14
E6581301
11
[14] Functions for lift [2/2]
Vector control
Title
Communi
cation
No.
Function Adjustment range
Minimum
setting unit
(Panel/Communi
cation)
Default
setting
Write during
running
Speed
control
Torque
control
PM
control
V/f Reference
H 0349
Acceleration/deceleration
suspend function
0:Deselect, 1:Parameter setting, 2:Terminal input 1/1 0 Disabled ●/● ●/● ● ● 6. 18
H 0350 Acceleration suspend frequency 0.0~HJ Hz 0.1/0.01 0.0 Enabled ●/● ●/● ● ● 6. 18
H 0351 Acceleration suspend time 0.0~10.0 sec. 0.1/0.1 0.0 Enabled ●/● ●/● ● ● 6. 18
H 0352 Deceleration suspend frequency 0.0~HJ Hz 0.1/0.01 0.0 Enabled ●/● ●/● ● ● 6. 18
H 0353 Deceleration suspend time 0.0~10.0 sec. 0.1/0.1 0.0 Enabled ●/● - ● ● 6. 18
[15] Commercial/inverter switching function
Vector control
Title
Communi
cation
No.
Function Adjustment range
Minimum
setting unit
(Panel/Communi
cation)
Default
setting
Write during
running
Speed
control
Torque
control
PM
control
V/f Reference
H 0354
Commercial power/inverter
switching output selection
0:OFF
1:Automatic switching in the event of a trip
2:Commercial power switching frequency setting
3:Commercial power switching frequency setting +
automatic switching in the event of a trip
1/1 0 Disabled ●/● ●/● ● ● 6. 19
H 0355
Commercial power/inverter
switching frequency
0~WN Hz 0.1/0.01 *2 Enabled ●/● ●/● ● ● 6. 19
H 0356
Inverter-side switching waiting
time
0.10~10.00 sec. 0.01/0.01 *1 Enabled ●/● ●/● ● ● 6. 19
H 0357
Commercial power-side
switching waiting time
0.40~10.00 sec. 0.01/0.01 0.62 Enabled ●/● ●/● ● ● 6. 19
H 0358
Commercial power switching
frequency holding time
0.10~10.00 sec. 0.01/0.01 2.00 Enabled ●/● ●/● ● ● 6. 19
*1: Default values vary depending on the capacity. ⇒ See the table of K-46.
*2: Inverter with a model number ending with -WN: 60.0 -WP: 50.0
[16] PID control [1/2]
Vector control
Title
Communi
cation
No.
Function Adjustment range
Minimum
setting unit
(Panel/Communi
cation)
Default
setting
Write during
running
Speed
control
Torque
control
PM
control
V/f Reference
H 0359 PID control switching
0:No PID control
1:Process type PID control (temp./pressure, etc.)
operation
2:Speed type PID control (potentiometer, etc.)
operation
3:Stop retaining P control
1/1 0 Disabled ●/● - ● ● 6. 21
H 0360
PID control feedback control
signal selection
0:Deviation input (no feedback input)
1:VI/II (voltage/current input)
2:RR/S4 (potentiometer/voltage input)
3:RX (voltage input)
4:Optional AI1 (differential current input)
5:Optional AI2 (voltage/current input)
6: PG feedback option
1/1 0 Disabled ●/● - ● ● 6. 21
H 0361 Delay filter 0.0~25.0 1/1 0.1 Enabled ●/● - ● ● *1
H 0362 Proportional (P) gain 0.01~100.0 0.01/0.01 0.10 Enabled ●/● - ● ● 6. 21
*1: ⇒ For details, refer to Instruction Manual (E6581329) specified in Section 6.41.
Sensorless vector/vector with sensor (●:Effective, -:Ineffective)
Sensorless vector/vector with sensor (●:Effective, -:Ineffective)
Sensorless vector/vector with sensor (●:Effective, -:Ineffective)
