2) Standard specifications (large capacity types) Note 4
Item Specification
Voltage class 200V class
Applicable motor (kW) 55 75
Type VFAS1-
Form 2550P 2750P
Output capacity
(kVA) Note 1:
84 109
Output current
(A)
221 285
Output voltage Three-phase 200V~230V (The maximum output voltage is equal to the input supply voltage.)
Ra
ting
Overload
current rating
150%-1 minute, 165%-2 sec.
Dynamic braking
circuit
Built-in dynamic braking drive circuit
Ele
ctr
ic
al
br
ak
in
g Dynamic braking
resistor An external braking resistor (optional)
⇒ Rating: Refer to 5.19.
Voltage-frequency Three-phase 200~240V-50/60Hz Note 5
Pow
er
su
pp
ly
Allowable
fluctuation
Voltage + 10 - 15% Note 3: Frequency ±5
Protective method IP00 Open type (JEM1030) Note 2
Cooling method Forced air-cooled
Color RAL7016
EMC filter External filter (optional)
DC reactor Attached DC reactor
Item Specification
Voltage class 400V class
Applicable motor (kW) 90 110 132 160 200 220 280 355 400 500
Type VFAS1-
Form 4900PC 4110KPC 4132KPC 4160KPC 4200KPC 4220KPC 4280KPC 4355KPC 4400KPC 4500KPC
Output capacity
(kVA) Note 1:
136 164 197 239 295 325 419 511 578 717
Output current
(A)
179 215 259 314 387 427 550 671 759 941
Output voltage Three-phase 380V~480V (The maximum output voltage is equal to the input supply voltage.)
Ra
ting
Overload
current rating
150%-1 minute, 165%-2 sec.
Dynamic
braking circuit
Built-in dynamic braking drive circuit External dynamic braking circuit (optional)
Ele
ctr
ic
al
br
ak
in
g
Dynamic braking
resistor An external braking resistor (optional)
⇒ Rating: Refer to 5.19.
Voltage-frequency Note 6
Three-phase 380~440V-50Hz
Three-phase 380~480V-60Hz
Note 5
Pow
er
su
pp
ly
Allowable
fluctuation
Voltage + 10 - 15% Note 3: Frequency ±5
Protective method IP00 Open type (JEM1030) 15% Note 2
Cooling method Forced air-cooled
Color RAL7016
EMC filter Built-in
DC reactor Attached DC reactor
Note 1: Capacity is calculated at 220V for the 200V models and at 440V for the 400V models.
Note 2: Inverters, 18.5kW or greater, do not have wiring port covers. They have large openings, but there is no space
to bend the external cables inside the unit. If they are fitted external to the cabinet, please use an optional
wiring port cover.
Note 3: ±10% when the inverter is used continuously (load of 100%).
Note 4: For 200V-55kW, 400V-90kW or larger model, be sure to install DC reactor (optional).
However, this is unnecessary for DC input specifications.
Note 5: An external power supply backup available (optional) (Type: CSP002Z)
Note 6: Three-phase 380~480V-50/60Hz for 4900PC
