Toshiba Tosvert VF-AS1 User Manual
Page 281
K-43
E6581301
11
[Output terminal function setting (1/3)]
Sensorless vector/vector with sensor (●: valid, -: invalid)
Positive
logic
Negative
logic
Function
Speed control Torque control
PM control
V/f
Reference
0
1
LL
●/●
●/●
●
●
2
3
UL
●/●
●/●
●
●
4
5
LOW
●/●
●/●
●
●
6
7
Acceleration/deceleration completion
●/●
-
●
●
8
9
Specified speed arrival
●/●
●/●
●
●
10
11
Failure FL (all trip)
●/●
●/●
●
●
12
13
Failure FL (except for EF, OCL, EPHO and OL2)
●/●
●/●
●
●
14
15
Overcurrent pre-alarm
●/●
●/●
●
●
16
17
Inverter overload pre-alarm
●/●
●/●
●
●
18
19
Motor overload pre-alarm
●/●
●/●
●
●
20
21
Overheat pre-alarm
●/●
●/●
●
●
22
23
Overvoltage pre-alarm
●/●
●/●
●
●
24
25
Main circuit undervoltage alarm
●/●
●/●
●
●
26
27
Low current alarm
●/●
●/●
●
●
28
29
Overtorque alarm
●/●
●/●
●
●
30
31
Braking resistor overload pre-alarm
●/●
●/●
●
●
32
33
In emergency stop
●/●
●/●
●
●
34
35
In course of retry
●/●
●/●
●
●
36
37
Pattern operation switching output
●/●
-
●
●
38
39
PID deviation limit
●/●
-
●
●
40
41
Run/Stop
●/●
●/●
●
●
42
43
Serious failure (OCA, OCL, EF, phase failure, etc.)
●/●
●/●
●
●
44
45
Light failure (OL, OC1, 2, 3, OP)
●/●
●/●
●
●
46
47
Commercial/INV switching output 1 (for inverter
operation output)
●/●
-
●
●
48
49
Commercial/INV switching output 2 (for commercial
operation output)
●/●
-
●
●
50
51
Cooling fan ON/OFF
●/●
●/●
●
●
52
53
In Jog run
●/●
-
●
●
54
55
Panel operation/terminal board operation switching
●/●
●/●
●
●
56
57
Cumulative operation time alarm
●/●
●/●
●
●
58
59
PROFIBUS/DeviceNet/CC-Link communication error
●/●
●/●
●
●
60
61
Forward/reverse run
●/●
●/●
●
●
62
63
Ready for operation 1
●/●
●/●
●
●
64
65
Ready for operation 2
●/●
●/●
●
●
68
69
Braking release signal
●/●
-
●
●
70
71
In (pre-)alarm status
●/●
●/●
●
●
72
73
Forward speed limit (torque control)
-
●/●
-
-
74
75
Reverse speed limit (torque control)
-
●/●
-
-
7.2.2
