TOSHIBA
4200FA UPS
Installation Planning Guide for 15-80kVA UPS
Standard System: 208/120V Input, 208/120V Output
Rev. 1.03 Page 1 of 2 4200FA-IPG-208v
General Mechanical Information
Dimensions
(W x D x H)
Weight Approximate Full-Load Heat Loss
UPS kVA/ kW Rating
Inches Lbs. kBtu/Hr
15 kVA/12 kW 20 x 36.25 x 59.85 900 5.7
25 kVA/ 20 kW 20 x 36.25 x 59.85 910 7.6
30 kVA/ 24 kW 20 x 36.25 x 59.85 915 9.1
50 kVA/ 40 kW 35.59 x 38.19 x 59.39 2,548 17.7
80 kVA/ 64 kW 44 x 31 x 74 1,560 40.0
Primary AC Input (208/120V 3-Phase / 4-Wire)
Maximum Input Power
Demand
Suggested External
Overcurrent Protection
Suggested Minimum Feeder
Wire Size Per Phase / Neutral
Suggested Maximum Feeder Length
For Min. Wire Size in Steel Conduit
kVA PF Amps Amps AWG or kcmil at 75º C Temp. Rating Feet
15 >0.97 45.7 60 AT (1) x 8 / (1) x 6 380
25 >0.97 76.3 90 AT (1) x 4 / (1) x 2 380
30 >0.97 92.4 125 AT (1) x 3 / (1) x 1 380
50 >0.97 152.6 200 AT (1) x 1/0 / (1) 4/0 380
80 >0.97 244.3 300 AT (1) x 300 / (1) x 500 380
Optional Alternate AC Input (208/120V 3-Phase / 4-Wire)
Maximum Input Power
Demand
Suggested External
Overcurrent Protection
Suggested Minimum Feeder
Wire Size Per Phase / Neutral
Suggested Maximum Feeder Length
For Min. Wire Size in Steel Conduit
kVA PF Amps Amps AWG at 75º C Temp. Rating Feet
15 >0.97 41.6 60 AT (1) x 8 / (1) x 6 380
25 >0.97 69.4 90 AT (1) x 4 / (1) x 2 380
30 >0.97 83.3 110 AT (1) x 3 / (1) x 1 380
50 >0.97 138.8 175 AT (1) x 1/0 / (1) 4/0 380
80 >0.97 222.1 300 AT (1) x 4/0 / (1) x 400 380
Battery Input (288VDC Nominal)
Battery Capacity Required
for Full Load Output
Maximum Discharge
at Full Load Output
Suggested External
Overcurrent Protection
Suggested Minimum Feeder
Wire Size Per Phase
Suggested Maximum Feeder Length
For Min. Wire Size in Steel Conduit
kWB Amps DC Amps AWG or kcmil at 75º C Temp. Rating Feet
15 13.33 61.7 90 AT (1) x 6 70
25 22.22 102.8 125 AT (1) x 2 70
30 26.67 123.0 175 AT (1) x 1 70
50 44.44 205.7 225 AT (1) x 4/0 70
80 71.11 329.2 400 AT (2) x 3/0 70
AC Output (208/120V 3-Phase / 4-Wire)
Rated Output Power
Suggested External
Overcurrent Protection
Suggested Minimum Feeder
Wire Size Per Phase / Neutral
Suggested Maximum Feeder Length
For Min. Wire Size in Steel Conduit
kVA PF Amps Amps AWG or kcmil at 75º C Temp. Rating Feet
15 0.8 41.6 60 AT (1) x 8 / (1) x 6 380
25 0.8 69.4 90 AT (1) x 4 / (1) x 2 380
30 0.8 83.3 110 AT (1) x 3 / (1) x 1 380
50 0.8 138.8 175 AT (1) x 1/0 / (1) 4/0 380
80 0.8 222.1 300 AT (1) x 4/0 / (1) x 400 380
