Toshiba Tosvert VF-AS1 - Manual (Page 285)

E6581301
L-1
12
12. Specifications
12.1 Models and their standard specifications
1) Standard specifications (small/medium capacity types)
Item Specification
Voltage class 200V class
Applicable motor (kW) 0.4 0.75 1.5 2.2 3.7/4.0 5.5 7.5 11 15 18.5 22 30 37 45
Type VFAS1-
Form 2004PL 2007PL 2015PL 2022PL 2037PL 2055PL 2075PL 2110PM 2150PM 2185PM 2220PM 2300PM 2370PM 2450PM
Output capacity (kVA)
Note 1:
1.1 1.8 3.0 4.2 6.7 10 13 21 25 29 34 46 55 67
Output current
(A) Note 2: 3.0
(3.0)
4.8
(4.5)
8.0
(8.0)
11
(10.5)
17.5
(16.6)
27.5
(25.0)
33
(33)
54
(49)
66
(64)
75
(64)
88
(73)
120
(88)
144
(120)
176
(144)
Output voltage Three-phase 200V~240V (The maximum output voltage is equal to the input supply voltage.)
Ra
ting
Overload
current rating
150%-1 minute, 165%-2 sec.
Dynamic
braking circuit
Built-in dynamic braking drive circuit
Ele
ctr
ic
al
br
ak
in
g Dynamic braking
resistor An external braking resistor (optional)
⇒ Rating: Refer to 5.19.
Voltage-frequency Three-phase 200~240V-50/60Hz Note 3
Pow
er
su
pp
ly
Allowable
fluctuation
Voltage + 10 - 15% Note 4: Frequency ±5
Protective method IP20 Enclosed type (JEM1030)
Cooling method Forced air-cooled
Color RAL7016
EMC filter Built-in Basic filter (Not complies with the European EMC Directive)
DC reactor External DC reactor (option) Built-in
Item Specification
Voltage class 400V class
Applicable motor (kW) 0.75 1.5 2.2 3.7/4.0 5.5 7.5 11 15 18.5 22 30 37 45 55 75
Type VFAS1-
Form 4007PL 4015PL 4022PL 4037PL 4055PL 4075PL 4110PL 4150PL 4185PL 4220PL 4300PL 4370PL 4450PL 4550PL 4750PL
Output capacity (kVA)
Note 1:
1.8 3.1 4.4 8.0 11 13 21 25 31 37 50 60 72 88 122
Output current
(A) 2.3
(2.3)
4.1
(4.0)
5.8
(5.3)
10.5
(8.6)
14.3
(13)
17.6
(17)
27.7
(25)
33
(32)
41
(32)
48
(37)
66
(44)
79
(60)
94
(72)
116
(90)
160
(110)
Output voltage Three-phase 380V~480V (The maximum output voltage is equal to the input supply voltage.)
Ra
ting
Overload
current rating
150%-1 minute, 165%-2 sec.
Dynamic
braking circuit
Built-in dynamic braking drive circuit
Ele
ctr
ic
al
br
ak
in
g Dynamic braking
resistor An external braking resistor (optional)
⇒ Rating: Refer to 5.19.
Voltage-
frequency
Three-phase 380~480V-50/60Hz Note 3
Pow
er
su
pp
ly
Allowable
fluctuation
Voltage + 10 - 15% Note 4: Frequency ±5
Protective method IP20 Enclosed type (JEM1030)
Cooling method Forced air-cooled
Color RAL7016
EMC filter Built-in
DC reactor External DC reactor (option) Built-in
Note 1: Capacity is calculated at 220V for the 200V models and at 440V for the 400V models.
Note 2: Rated output current when the PWM carrier frequency (parameter EH) is 4kHz or less.
The values between parentheses refer to rated output currents when set to 12kHz.
⇒ Refer to 5.17 for details.
Note 3: If you are using a 200V-15kW or 400V-2.2kW inverter and the ambient temperature is 40°C or more, decrease
the PWM carrier frequency to 8kHz. Setting H to enables you to protect the overload caused by
ambient temperature described in page A-21.
Note 4: An external power supply backup available (optional) (Type: CPS002Z)
Note 5: ±10% when the inverter is used continuously (load of 100%).
