K-8
E6581301
11
[5] V/f 5-point setting
Vector control
Title
Communi
cation
No.
Function Adjustment range
Minimum
setting unit
(Panel/Communi
cation)
Default
setting
Write during
running
Speed
control
Torque
control
PM
control
V/f Reference
H 0190
V/f 5-point setting VF1
frequency
0.0~HJ Hz 0.1/0.01 0.0 Disabled - - ● ● 5. 6
H 0191 V/f 5-point setting VF1 voltage 0.0~100.0% 0.1/0.01 0.0 Disabled - - ● ● 5. 6
H 0192
V/f 5-point setting VF2
frequency
0.0~HJ Hz 0.1/0.01 0.0 Disabled - - ● ● 5. 6
H 0193 V/f 5-point setting VF2 voltage 0.0~100.0% 0.1/0.01 0.0 Disabled - - ● ● 5. 6
H 0194
V/f 5-point setting VF3
frequency
0.0~HJ Hz 0.1/0.01 0.0 Disabled - - ● ● 5. 6
H 0195 V/f 5-point setting VF3 voltage 0.0~100.0% 0.1/0.01 0.0 Disabled - - ● ● 5. 6
H 0196
V/f 5-point setting VF4
frequency
0.0~HJ Hz 0.1/0.01 0.0 Disabled - - ● ● 5. 6
H 0197 V/f 5-point setting VF4 voltage 0.0~100.0% 0.1/0.01 0.0 Disabled - - ● ● 5. 6
H 0198
V/f 5-point setting VF5
frequency
0.0~HJ Hz 0.1/0.01 0.0 Disabled - - ● ● 5. 6
H 0199 V/f 5-point setting VF5 voltage 0.0~100.0% 0.1/0.01 0.0 Disabled - - ● ● 5. 6
[6] Speed/torque reference gain/bias setup [1/2]
Vector control
Title
Communi
cation
No.
Function Adjustment range
Minimum
setting unit
(Panel/Communi
cation)
Default
setting
Write during
running Speed
control
Torque
control
PM
control
V/f Reference
H 0200 Frequency priority selection
0:HOQF/H terminal switching (input
terminal function selection 104, 105)
1:HOQF/H frequency switching (switching
with H)
1/1 0 Enabled ●/● - ● ● 6. 6. 1
H 0201 VI/II input point 1 setting 0~100% 1/1 0 Enabled ●/● ●/● ● ● 7. 3. 2
H 0202 VI/II input point 1 frequency 0.0~HJ Hz 0.1/0.01 0.0 Enabled ●/● - ● ● 7. 3. 2
H 0203 VI/II input point 2 setting 0~100% 1/1 100 Enabled ●/● ●/● ● ● 7. 3. 2
CKH 0204 VI/II input point 2 frequency 0.0~HJ Hz 0.1/0.01 *1 Enabled ●/● - ● ● 5. 11
H 0205 VI/II input point 1 rate 0~250% (for torque control etc.) 1/0.01 0 Enabled ●/● ●/● - - *2
H 0206 VI/II input point 2 rate 0~250% (for torque control etc.) 1/0.01 100 Enabled ●/● ●/● - - *2
H 0207
Frequency setting mode
selection 2
Same as HOQF (1~13) 1/1 Disabled ●/● - ● ● 6. 6. 1
H 0208
Speed command priority
switching frequency
0.1~HJ Hz 0.1/0.01 0.1 Enabled ●/● - ● ● 6. 6. 1
H 0209 Analog input filter
0:No filter
1:Filter approx. 10ms
2:Filter approx. 15ms
3:Filter approx. 30ms
4:Filter approx. 60ms
1/1 0 Enabled ●/● ●/● ● ● 7. 2. 4
H 0210 RR/S4 input point 1 setting 0~100% 1/1 0 Enabled ●/● ●/● ● ● 7. 3. 1
H 0211 RR/S4 input point 1 frequency 0.0~HJ Hz 0.1/0.01 0.0 Enabled ●/● - ● ● 7. 3. 1
This parameter moves to a fundamental parameter.
*1: Inverter with a model number ending with -WN: 60.0 -WP: 50.0
*2: ⇒ For details, refer to Instruction Manual (E6581331) specified in Section 6.41.
Sensorless vector/vector with sensor (●:Effective, -:Ineffective)
Sensorless vector/vector with sensor (●:Effective, -:Ineffective)
