K-42
E6581301
11
[Input terminal function setting (2/2)]
Sensorless vector/vector with sensor (●: valid, -: invalid)
Positive
logic
Negative
logic
Function
Speed
control
Torque
control
PM control
V/f
EOQF
=
H
=
Reference
70
71
Servo lock signal
●/●
-
●
●
●
-
72
73
Simple positioning (positioning loop)
●/●
-
●
●
●
-
74
75
Integrating wattmeter display clear
●/●
-
●
●
●
-
76
77
Trace back trigger signal
●/●
-
●
●
●
-
78
79
Light-load high-speed operation prohibitive signal
●/●
-
●
●
●
-
86
87
Binary data write
●/●
●/●
●
●
●
-
88
89
Up/Down frequency (up)*1
●/●
-
●
●
●
-
90
91
Up/Down frequency (down)*1
●/●
-
●
●
●
-
92
93
Up/Down frequency (clear)
●/●
-
●
●
●
-
98
99
Forward/reverse selection
●/●
●/●
●
●
●
-
100
101
Run/Stop command
●/●
●/●
●
●
●
-
102
103
Commercial power/INV switching
●/●
-
●
●
●
-
104
105
Frequency reference priority switching
●/●
-
●
●
●
-
106
107
VI/II terminal priority
●/●
-
●
●
●
-
108
109
Command terminal board priority
●/●
●/●
●
●
●
-
110
111
Parameter editing enabling
●/●
●/●
●
●
●
-
112
113
Control switching (torque/position)
●/●
●/●
-
-
*2
-
122
123
Rapidest deceleration command
●/●
-
●
●
●
-
124
125
Preliminary excitation
●/●
●/●
●
●
●
-
126
127
Braking request
●/●
-
●
●
●
-
130
131
Brake answer back input
●/●
-
●
●
●
-
134
135
Traverse permission signal
●/●
-
●
●
●
-
7.2.1
*1: The deceleration/deceleration time depends on the CEE/FGE setting, unless switching between acceleration and deceleration is performed.
*2: Dependent on EOQF.
