E6581301
G-8
7
Parameter setting
Positive
logic
Negative
logic
Function Operation output specifications (in case of positive logic)
Specified data output
1
Specified data output
2
Specified data output
3
Specified data output
4
Specified data output
5
Specified data output
6
Specified data output
7
Output of the designated data in 7-bit.
Light load output ON:Load is equal to H~H set values or less.
Heavy load output ON:Load is larger than H~H set value.
Positive torque limit ON:Positive torque is over the positive torque limit level.
Negative torque limit ON:Negative torque is over the positive torque limit level.
Output for external rush
suppression relay
ON:External rush suppression relay is actuated.
Completion of stop
positioning
ON:Stop positioning has been completed.
L-STOP
ON:Operation at the lower limit frequency is performed
continuously.
Power failure
synchronized operation
ON:Power failure synchronized operation is performed.
Traverse in progress ON:Traverse operation is performed.
Traverse deceleration in
progress
ON:Traverse deceleration operation is performed.
Part replacement alarm Alarm:The time of replacement of parts is approaching.
Over-torque pre-alarm ON:Over-torque is detected.
Frequency command 1/
2 selection
ON:Frequency command selection 2 is selected.
Failure FL (Except
emergency stop)
ON:A trip other than emergency stop has occurred.
My function output 1 ON:My function output 1 is ON.
My function output 2 ON:My function output 2 is ON.
My function output 3 ON:My function output 3 is ON.
My function output 4 ON:My function output 4 is ON.
My function output 5 ON:My function output 5 is ON.
My function output 6 ON:My function output 6 is ON.
My function output 7 ON:My function output 7 is ON.
My function output 8 ON:My function output 8 is ON.
My function output 9 ON:My function output 9 is ON.
My function output 10 ON:My function output 10 is ON.
My function output 11 ON:My function output 11 is ON.
My function output 12 ON:My function output 12 is ON.
My function output 13 ON:My function output 13 is ON.
My function output 14 ON:My function output 14 is ON.
My function output 15 ON:My function output 15 is ON.
My function output 16 ON:My function output 16 is ON.
Always OFF (for terminal
signal tests)
Output signal always OFF
Note 1: “ON” in positive logic : Open collector output transistor or relay is turned on.
“OFF” in positive logic : Open collector output transistor or relay is turned off.
“ON” in negative logic : Open collector output transistor or relay is turned off.
“OFF” in negative logic : Open collector output transistor or relay is turned on.
Note 2: Alarm output check conditions are as follows.
(1) Undervoltage detected :To be checked during operation.
(2) Low current detected
: To be checked during operation command.
(3) Overtorque detected : To be checked always.
■ Sink logic/source logic
Sink logic and source logic (logic of input/output terminal) can be switched to each other.
⇒ For details, refer to Section 2.3.2.
