10. Selection of peripheral devices
Danger
Mandatory
• When using the inverter without the front cover, be sure to place the inverter unit inside a cabinet. If
they are used outside the cabinet, it may cause electric shock.
Be Grounded
• Be sure to ground every unit. If not, it may cause electric shock or fire on the occasion of failure,
short-circuit or electric leak.
10.1
Selection of wiring materials and devices
Wire size
Main circuit (*1)
DC reactor
(optional)
Braking resistor/
Braking unit
(optional) (*5)
Earth cable
Voltage
class
Applicable
motor
[kW]
Inverter model
AWG
mm
2
AWG
mm
2
AWG
mm
2
AWG
mm
2
0.4
VFAS1-2004PL
14
2
14
2
14
2
12
3.5
0.75
VFAS1-2007PL
14
2
14
2
14
2
12
3.5
1.5
VFAS1-2015PL
14
2
14
2
14
2
12
3.5
2.2
VFAS1-2022PL
14
2
14
2
14
2
12
3.5
3.7/4.0
VFAS1-2037PL
12
3.5
14
2
14
2
12
3.5
5.5
VFAS1-2055PL
10
5.5
12
3.5
10
5.5
10
5.5
7.5
VFAS1-2075PL
8
8
10
5.5
10
5.5
8
8
11
VFAS1-2110PM
6
14
8 (*6)
8
10
5.5
6
14
15
VFAS1-2150PM
6
14
6 (*6)
14
10
5.5
6
14
18.5
VFAS1-2185PM
4
22
4 (*6)
22
8
8
4
22
22
VFAS1-2220PM
4
22
4 (*6)
22
6
14
4
22
30
VFAS1-2300PM
2
38
2 (*6)
38
6
14
4
22
37
VFAS1-2370PM
1/0
60
1/0 (*6)
60
4
22
2
38
45
VFAS1-2450PM
1/0
60
4/0 (*6)
100
4
22
2
38
55
VFAS1-2550P
4/0
100
4/0
100
4
22
1/0
60
200V
class
75
VFAS1-2750P
300MCM
150
300MCM
150
2
38
4/0
100
0.75
VFAS1-4007PL
14
2
14
2
14
2
12
3.5
1.5
VFAS1-4015PL
14
2
14
2
14
2
12
3.5
2.2
VFAS1-4022PL
14
2
14
2
14
2
12
3.5
3.7/4.0
VFAS1-4037PL
14
2
14
2
14
2
12
3.5
5.5
VFAS1-4055PL
14
2
14
2
14
2
12
3.5
7.5
VFAS1-4075PL
12
3.5
14
2
14
2
12
3.5
11
VFAS1-4110PL
10
5.5
12
3.5
14
2
10
5.5
15
VFAS1-4150PL
8
8
10
5.5
14
2
8
8
18.5
VFAS1-4185PL
8
8
10 (*6)
5.5
10
5.5
8
8
22
VFAS1-4220PL
8
8
8 (*6)
8
10
5.5
8
8
30
VFAS1-4300PL
6
14
6 (*6)
14
10
5.5
6
14
37
VFAS1-4370PL
4
22
4 (*6)
22
6
14
4
22
45
VFAS1-4450PL
2
38
4 (*6)
22
6
14
4
22
55
VFAS1-4550PL
2
38
2 (*6)
38
6
14
4
22
75
VFAS1-4750PL
1/0
60
1/0 (*6)
60
6
14
2
38
90
VFAS1-4900PC
1/0
60
1/0
60
4
22
2
38
110
VFAS1-4110KPC
4/0
100
4/0
100
4
22
1
60
132
VFAS1-4132KPC
4/0
100
300MCM
150
4
22
1
60
160
VFAS1-4160KPC
300MCM
150
300MCM
150
4
22
4/0
100
200
VFAS1-4200KPC
400MCM
200
300MCM×2
150×2
1/0
60
4/0
100
220
VFAS1-4220KPC
400MCM
200
300MCM×2
150×2
1/0
60
4/0
100
280
VFAS1-4280KPC 300MCM×2
150×2
400MCM×2
200×2
4/0
100
300MCM
150
355
VFAS1-4355KPC
400
VFAS1-4400KPC
400V
class
500
VFAS1-4500KPC
(*1): Indicates wire sizes of input terminals R, S, T and output terminals U,V,W.
(*2): The recommended cable size is that of the cable (e.g. 600V class,HIV cable) with continuous maximum permissible
temperature of 75°C. Ambient temperature is 50°C or less and the wiring distance is 30m or less.
(*3): For the control circuit, use shielded wires whose size (cross-section) is 0.75 mm
2
or more.
(*4): For the earth cable, use wires larger than the specified ones in size (cross-section).
(*5): Recommended wire size for an optional braking resistor. Refer to 5.19 for use of external braking resistor.
(*6): Recommended wire size for internal DC reactor.
