K-33
E6581301
11
[29] My function [1/5]
Vector control
Title
Communi
cation
No.
Function Adjustment range
Minimum
setting unit
(Panel/Communi
cation)
Default
setting
Write during
running
Speed
control
Torque
control
PM
control V/f Constant Reference
H 0900 Input function target 11
Input terminal function number
0:Deselect
1:F terminal
2:R terminal
3:ST terminal
4:RES terminal
5:S1 terminal
6:S2 terminal
7:S3 terminal
8:RR/S4 terminal
9:LI1 terminal
10:LI2 terminal
11:LI3 terminal
12:LI4 terminal
13:LI5 terminal
14:LI6 terminal
15:LI7 terminal
16:LI8 terminal
17:B12 terminal
18:B13 terminal
19:B14 terminal
20:B15 terminal
21:Virtual input terminal 1
22:Virtual input terminal 2
23:Virtual input terminal 3
24:Virtual input terminal 4
25~32:Internal terminal 1~8
918~934:MY function number
1000~1255:Output selection number
2000~2099:FD00~FD99
3000~3099:FE00~FE99
1/1 0 Disabled ●/● ●/● ● ● *1
*1: ⇒ For details, refer to Instruction Manual (E6581335) specified in Section 6.41.
Sensorless vector/vector with sensor (●:Effective, -:Ineffective)
